150 ton small grain steel silo sales at factory price cheap cereal processing animal feed grain silo with accessories bin silo

150 ton small grain steel silo sales at factory price cheap cereal processing animal feed grain silo with accessories bin silo

FOB Reference Price: Get Latest Price

≥1 Sets

US $6340

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: Famtun steel silos

Dimension(L*W*H):: 5.5x5.5x40.3m

Weight:: 3600 KG

Name:: 150t galvanized grain storage silo for animal feed

Usage:: Grain Storage Silos

Application:: Farming Industry

Bottom Type:: flat Bottom

Silo Materials:: Hot Galvanized Steel

Handling equipments:: Conveyor, elevator

Auxillary System:: Cleaning, ventilation system

Key words:: grain storage silos

After sales Service Provided:: Field installation, commissioning and training

After-sales Service Provided:: Field maintenance and repair service

Quick Details

Marketing Type:: customized silos

Core Components:: grian storage silos

Place of Origin:: Shandong, China

Brand Name:: Famtun steel silos

Dimension(L*W*H):: 5.5x5.5x40.3m

Weight:: 3600 KG

Name:: 150t galvanized grain storage silo for animal feed

Usage:: Grain Storage Silos

Application:: Farming Industry

Bottom Type:: flat Bottom

Silo Materials:: Hot Galvanized Steel

Handling equipments:: Conveyor, elevator

Auxillary System:: Cleaning, ventilation system

Key words:: grain storage silos

After sales Service Provided:: Field installation, commissioning and training

After-sales Service Provided:: Field maintenance and repair service

Product Overview

TCZ05508 150T flat bottom grain storage silo

1. Famtun flat bottom steel silo series is specially designed by senior engineers in our company, manufactured by high-quality galvanizing board.
2.. All Famtun silos are engineered with precision from high strength, 80mm x 14mm corrugated steel plate, normally
galvanised thickness is 275 g/m2.
3. The service life of the silos could last up to 30-50 years long. Complying with the national standard of
GB50322-2001 while the products are designed and manufactured.
4. Famtun hopper bottom steel silos provide the best quality grain storage option available. Construction period of the most popular 250t, 500t and 1,000t capacity silos is efficient,and can typically be completed in around 10 days per silo

Products Description

Diameter	model No.	volume capacity	weight capacity (720kg/m3)	Pcs.* Rings	Total Height	Silo Height	top roof Height
5.5 m	TCZ05508	224m3	161MT	6*8	10.3m	9.02m	1.28m

FEATURES AT A GLANCE

SILOS CAPACITY CUSTOMIZATION

LIGHT WEIGHT(1/5 WEIGHT OF CONCRETE SILO)

LONG SERVICE LIFE (30-50YEARS)

INTELLIGENT CONTROLLING SYSTEM

INTERCHANGEABILITY

LARGE CAPACITY RANGE (5T-16000T)

SHORT CONSTRUCTION PERIOD

hopper bottom

flat bottom

small animal feeding silo

bolt assemblage

1.Silo: the silo wall sheets are corrugated that is made of high quality galvanizing board; the sheets are bolted together by common or high strengthen bolts. The thickness of silo wall is designed according to the strength theory, which makes the whole wall can afford even swelling tension. At the same time, the interior vertical stiffeners can afford the vertical friction. It is 0.96m between every two stiffeners, the cutting face is in the shape of "V", and there are spherical waterproof washers in the bolts' hole and water proof mastic bars between every two pieces of silo sheet. The handle equipments can make it more convenient to maintenance or unloading, such as silo doors, interior and exterior ladder and protecting net

beam

2. Radial beam silo roof support system: the roof is made of galvanizing board that is 0.8mm thick, and bolts are with galvanizing
die. There are special equipments on the silo roof such as natural vents, manhole, roof ladders, and secure cages and so on

roofing

. 3.The main parts of the silo bin and roof are made of galvanizing board or spares which can make silo become even more steady and
durable with longer life time, which is good to realize automatic work

Manufacturing Technique

CORRUGATED STEEL MOLDING LINE

NUMERICAL CONTROL SHEARING MACHINE

LASER CUTTING MACHINE

SALES AND SERVICE NETWORK

Successful Project

GAN SU ,WU WEI PROJECT

HEILONGJIANG, TAILAI PROJECT

XINJIANG, TACHENG PROJECT

Product packaging
