- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
1 year, 12 Months/1000 Hours
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Eleclink
-
Model Number:
-
ELC-S360GF
-
Speed:
-
1500/1800RPM
-
Weight:
-
3000KG
-
Products Name:
-
Generator
-
Alternator:
-
Stamford /Marathon
-
Type:
-
open type
-
Controller:
-
Smartgen
-
Certificate:
-
CE/ISO9001
-
Customized Logo:
-
Accept
-
Fuel Tank:
-
8 hours fuel tank
-
Color:
-
As the picture
-
MOQ:
-
1Sets
-
Certification:
-
ISO CE
Quick Details
-
Rated Voltage:
-
400V
-
Rated Current:
-
648A
-
Frequency:
-
50/60HZ
-
Warranty:
-
1 year, 12 Months/1000 Hours
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Eleclink
-
Model Number:
-
ELC-S360GF
-
Speed:
-
1500/1800RPM
-
Weight:
-
3000KG
-
Products Name:
-
Generator
-
Alternator:
-
Stamford /Marathon
-
Type:
-
open type
-
Controller:
-
Smartgen
-
Certificate:
-
CE/ISO9001
-
Customized Logo:
-
Accept
-
Fuel Tank:
-
8 hours fuel tank
-
Color:
-
As the picture
-
MOQ:
-
1Sets
-
Certification:
-
ISO CE
Related Products
|
Search By Power
|
|
|
|
|
||||
|
|
||||||||
|
Searching By Engine
|
|
|
|
|
||||
|
|
||||||||
400kva 360kw Big Size Used Diesel Generator With Shangchai Engine SC25G610D2 Brushless Alternator Price
Specification
|
Model
|
Voltage
|
HZ
|
P.F
（COS￠） |
Standby power
|
Prime power
|
|
ELC-S360GF
|
110、230、400V
|
50/60Hz
|
0.8
|
500kva/400kw
|
360KW/400KVA
|
|
Engine Model
|
SC25G610D2
|
|
|
Number of Cylinders
|
6cylinders
|
|
|
Cycle
|
4 stroke
|
|
|
Aspiration
|
Turbocharged and after water cooled
|
|
|
Bore×Stroke
|
135mm x165mm
|
|
|
Displacement
|
14.2L
|
|
|
Fuel Consumption at 100% Load
|
207g/kw.h
|
|
|
Starter Motor
|
DC24V,
|
|
|
Alternator
|
Stamford/Marathon/Leroysomer/Eleclink
|
|
|
Prime power
|
400KVA
|
|
|
Frequency/speed
|
50/60Hz
|
|
|
Exciter type
|
Brushless
|
|
|
Power factor
|
0.8
|
|
|
Voltage adjust range
|
≥±5%
|
|
|
Voltage regulation NL-FL
|
±0.5%
|
|
|
Insulation Grade
|
H
|
|
|
Protection Grade
|
IP23
|
|
|
Phase
|
Three phases
|
|
|
Smartgen control panel data
|
|
|
|
Controller Brand
|
Deepsea /ComAp /Smartgen
|
|
|
Controller Display
|
Output frequency
Engine speed Battery voltage
Engine run-time (Hours)
Note: 1. The engine coolant temperature displayed by water temperature gauge 2. The engine oil pressure displayed by oil pressure meter 3. Generator current displayed by current meter, to change switch for each phase displayed separately |
|
|
Generator Set
|
Fuel System
|
Control system
|
Alternator
|
Low environment temperature
|
|
8h/12h/24hours fuel tank
|
AMF function
|
PMG excitation
|
Water heater
|
|
|
Dual wall base fuel tank
|
ATS
|
Space heater
|
Oil heater
|
|
|
Outside fuel tank
|
Multiple generator automatic synchrorising
|
|
Battery heater
|
