Quick Details
-
Material:
-
Bearing steel
-
Length customization:
-
850mm/900mm/950mm/1000mm
-
Position Accuracy:
-
0.05mm
-
Screw Precision Grade:
-
C7
-
Screw Type:
-
1610
-
Stepper Motor Type:
-
60-102
-
Stepper Motor Controller:
-
as to your requirements
-
Materail:
-
Bearing steel
-
Application:
-
Automatic System
-
Package:
-
Carton Box
Quick Details
-
Model Number:
-
SW80/850mm-1000mm
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
UMot
-
Material:
-
Bearing steel
-
Length customization:
-
850mm/900mm/950mm/1000mm
-
Position Accuracy:
-
0.05mm
-
Screw Precision Grade:
-
C7
-
Screw Type:
-
1610
-
Stepper Motor Type:
-
60-102
-
Stepper Motor Controller:
-
as to your requirements
-
Materail:
-
Bearing steel
-
Application:
-
Automatic System
-
Package:
-
Carton Box
Product Description
Product Paramenters
|
Brand:
|
UMot
|
|
Material:
|
Bearing steel
|
|
Effective Stroke
|
850mm,900mm,950mm,1000mm
|
|
Position Accuracy:
|
±0.05mm
|
|
Screw Precision Grade:
|
C7
|
|
Stepper Motor Type:
|
Nema 24
|
|
Max Horizontal Loadings
|
40kg
|
|
Max Vertical Loading
|
20kg
|
|
Limit switch:
|
2 for free
|
|
Without Loading Speed
|
220mm/s
|
|
Max Horizontal Full Speed
|
210mm/s
|
|
Max Vertical Full Speed
|
60mm/s
|
|
Rated Acceleration
|
500mm/s
|
|
Maximum thrust
|
452N
|
Packing & Delivery
Foam+Hard Carton or Wooden Case+Waterproof film
