Quick Details
-
Warranty(Year):
-
7-Year
-
Lamp Luminous Flux(lm):
-
25000
-
Working Temperature(℃):
-
-40 - 65
-
Working Lifetime(Hour):
-
100000
-
Place of Origin:
-
China
-
LED Chip:
-
Nichia
-
Certification1:
-
CCC
-
Certification2:
-
ce
-
Certification3:
-
C-tick
-
Certification4:
-
RoHS
-
Certification5:
-
Saa
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
160
-
Lamp Body Material:
-
Aluminum
-
Application:
-
Warehouse
-
Warranty(Year):
-
7-Year
-
Lamp Luminous Flux(lm):
-
25000
-
Working Temperature(℃):
-
-40 - 65
-
Working Lifetime(Hour):
-
100000
-
Place of Origin:
-
China
-
LED Chip:
-
Nichia
-
Certification1:
-
CCC
-
Certification2:
-
ce
-
Certification3:
-
C-tick
-
Certification4:
-
RoHS
-
Certification5:
-
Saa
Features
• Perfect solution for high temperature working places, lifetime can reach 50,000Hrs when Ta=65℃.
• 160LM/W system efficiency,top level in the market
• Original Nichia chips, highest efficiency 210LM/W LED.
• Original designed cooling system,minimized the weight and volume of heat sink per watt.
• Philips Xitaninum driver,high efficiency and 100,000 hours life span.
• 1-10V dimming,motion sensor and daylight sensor functions can be option.
• 7 Years Warranty.
Specification
|
Product Code
|
Dimension(mm)
|
Power
|
Input Voltage
|
Beam Angle
|
Efficiency
|
Lumen Output(LM) @5700K
|
|
HS-HB1505-70W-XX
|
Φ280*350
|
70W
|
AC220-240V
50/60Hz
|
80°(45°/60°/ 90°/120°)
|
160LM/W
|
11,000
|
|
HS-HB1505-97W-XX
|
Φ280*357
|
97W
|
|
|
|
15,500
|
|
HS-HB1505-122W-XX
|
Φ280*367
|
122W
|
|
|
|
19,000
|
|
HS-HB1505-160W-XX
|
Φ280*377
|
160W
|
|
|
|
25,000
|
XX represents function such as ND(Non-dimmable),D(Dimmable),SD(Sensor).
