Quick Details
-
Insulation Material:
-
Other
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
micc for chromel alumel thermocouple wire
-
Model Number:
-
chromel alumel thermocouple wire
-
product:
-
Best sell chromel alumel thermocouple k wire with high quality
-
type:
-
k
-
color:
-
gray
-
Certificate::
-
ISO,CQC ROHS
-
Trade term::
-
FOB, EXW, CIF, CFR
-
Conductor Material::
-
NiCr,Cu,CuNi,NiSi,Fe
-
brand:
-
micc
-
Product Size::
-
0.05mm to 10.0mm
Quick Details
-
Application:
-
Heating
-
Conductor Material:
-
Other
-
Conductor Type:
-
Other
-
Insulation Material:
-
Other
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
micc for chromel alumel thermocouple wire
-
Model Number:
-
chromel alumel thermocouple wire
-
product:
-
Best sell chromel alumel thermocouple k wire with high quality
-
type:
-
k
-
color:
-
gray
-
Certificate::
-
ISO,CQC ROHS
-
Trade term::
-
FOB, EXW, CIF, CFR
-
Conductor Material::
-
NiCr,Cu,CuNi,NiSi,Fe
-
brand:
-
micc
-
Product Size::
-
0.05mm to 10.0mm
thermocouple k wire
Classification
1. Thermocouple level (high temperature level). This type of thermocouple wire is mainly suitable for thermocouple type K, J, E, T, N and L and other high temperature detection instrument, temperature sensor, etc.
2.
Compensating wire level (low temperature level). This type of thermocouple wire is mainly suitable for compensating cable and extension wire of various thermocouples of type S, R, B, K, E, J, T, N and L, heating cable, control cable and so on.
Advantage of thermocouple k wire
High quality with high measuring accuracy, fast thermal response, high mechanical strength, long service lifetime, wide temp measuring range of -200-1300centigrade .
Thermocouple variety and index of thermocouple k wire
|
Thermocouple Variety and Index |
||
|
Variety |
Type |
Measurement Range(°C) |
|
NiCr-NiSi |
K |
–200–1300 |
|
NiCr-CuNi |
E |
–200–900 |
|
Fe-CuNi |
J |
–40–750 |
|
Cu-CuNi |
T |
–200–350 |
|
NiCrSi-NiSi |
N |
–200–1300 |
|
NiCr-AuFe0.07 |
NiCr-AuFe0.07 |
–270–0 |
Thermocouple type and grade of thermocouple k wire
|
Thermocouple Type |
Grade |
Temperature Range(°C) |
Allowable Deviation |
|
type K and type N |
I |
–40–1100 |
±1.5°C or±0.4%t |
|
II |
–40–1300 |
±2.5°C or ±0.75%t |
|
|
III |
–200–40 |
±2.5°C or ±1.5%t |
|
|
type E |
I |
–40–1100 |
±1.5°C or ±0.4%t |
|
II |
–40–1300 |
±2.5°C or ±0.75%t |
|
|
III |
–200–40 |
±2.5°C or±1.5%t |
|
|
type J |
I |
–40–750 |
±1.5°C or ±0.4%t |
|
II |
–40–750 |
±2.5°C or ±0.75%t |
|
|
type T |
I |
–40–350 |
±0.5°C or± 0.4%t |
|
II |
–40–350 |
±1.0°C or± 0.75%t |
|
|
III |
–200–40 |
±1.0°C or± 1.5%t |
|
|
NiCr-AuFe0.07 |
I |
–270–0 |
±0.5°C |
|
II |
±1.0°C
|
Specification of thermocouple k wire
|
Anode |
Cathode |
Diameter(mm) |
Maximum Temperature(°C) |
|||
|
name |
code |
name |
code |
long-time using |
short-time using |
|
|
NiCr10(Chromel) |
KP |
NiSi3(Alumel) |
KN |
Φ0.3 |
700 |
800 |
|
Φ0.5 |
800 |
900 |
||||
|
Φ0.8 Φ1.0 |
900 |
1000 |
||||
|
Φ1.2 Φ1.6 |
1000 |
1100 |
||||
|
Φ2.0 Φ2.5 |
1100 |
1200 |
||||
|
NiCr14.2Si |
NP |
NiSi4 |
NN |
Φ3.2 |
1200 |
1300 |
|
NiCr10(Chromel) |
EP |
CuNi45(Copel) |
EN |
Φ0.3 Φ0.5 |
350 |
450 |
|
Φ0.8 Φ1.0 Φ1.2 |
450 |
550 |
||||
|
Φ1.6 Φ2.0 |
550 |
650 |
||||
|
Φ2.5 |
650 |
750 |
||||
|
Φ3.2 |
750 |
900 |
||||
|
Fe(Iron) |
JP |
CuNi45(Copel) |
JN |
Φ0.3 Φ0.5 |
300 |
400 |
|
Φ0.8 Φ1.0 Φ1.2 |
400 |
500 |
||||
|
Φ1.6 Φ2.0 |
500 |
600 |
||||
|
Φ2.5 Φ3.2 |
600 |
750 |
||||
|
Cu(Copper) |
TP |
CuNi45(Copel) |
TN |
Φ0.2 Φ0.3 |
150 |
200 |
|
Φ0.5 Φ0.8 |
200 |
250 |
||||
|
Φ1.0 Φ1.2 |
250 |
300 |
||||
|
Φ1.6 Φ2.0 |
300 |
350
|
||||
