Quick Details
-
Brand Name:
-
Btutest
-
Model Number:
-
BTU960
-
Name:
-
Cross Hole Ultrasonic System FOUR channels automatic
-
Operational mode:
-
Touch screen
-
One-time section mumber:
-
6
-
Channel number:
-
4(transmit and receive)
-
Trigger mode:
-
Signal triggering
-
Sampling period(μs):
-
0.05~409.6 Multistage Options
-
Acoustic time accuracy(μs):
-
0.05
-
Acoustic time range(μs):
-
+1677700
-
Host size(mm):
-
300*200*55
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Electronic
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Btutest
-
Model Number:
-
BTU960
-
Name:
-
Cross Hole Ultrasonic System FOUR channels automatic
-
Operational mode:
-
Touch screen
-
One-time section mumber:
-
6
-
Channel number:
-
4(transmit and receive)
-
Trigger mode:
-
Signal triggering
-
Sampling period(μs):
-
0.05~409.6 Multistage Options
-
Acoustic time accuracy(μs):
-
0.05
-
Acoustic time range(μs):
-
+1677700
-
Host size(mm):
-
300*200*55
Product Description
Cross Hole Ultrasonic System FOUR channels automatic
Standard:
ASTM D6760-02
Description:
Rapid and continuous detection of foundation piles by ultrasonic transmission method; Rapid detection of continuous wall
integrity; Structural concrete compressive strength test; Detection of crack depth of structural concrete; Detection of crack
width of structural concrete; Bending resistance test of concrete pavement; Mechanical property testing of non-metallic materials such as rock mass and concrete.
ASTM D6760-02
Description:
Rapid and continuous detection of foundation piles by ultrasonic transmission method; Rapid detection of continuous wall
integrity; Structural concrete compressive strength test; Detection of crack depth of structural concrete; Detection of crack
width of structural concrete; Bending resistance test of concrete pavement; Mechanical property testing of non-metallic materials such as rock mass and concrete.
Features:
※ newly upgraded wireless cloud transmission function;
※ stable performance and powerful function, it is the choice of users with diversified needs in engineering testing, teaching and scientific research;
※ it integrates six functions of pile, strength, defect, width, depth and pavement bending resistance;
※ semi reflective and semi transparent, high brightness, TFT color LCD screen;
※ full touch screen operation, simple and convenient, stable and reliable;
※ multi channel automatic acquisition, automatic recording of height and sound waveform;
※ the depth recording wheel adopts dust-proof and waterproof design;
※ large memory capacity and working time of more than 10 hours;
※ it can be directly connected to the digital rebound meter probe for ultrasonic rebound comprehensive strength measurement;
※ the U disk is used to transfer data and support software upgrading through the U disk;
※ the special analysis software has powerful functions, and data analysis and processing, report generation, and printing of reports can be easily completed;
※ the transducer spool is designed with a collector ring, and the signal cable can be retracted and retracted freely to prevent the cable from being twisted;
※ the Chinese and English interfaces can be switched freely, making it more convenient for foreign customers to use.
※ stable performance and powerful function, it is the choice of users with diversified needs in engineering testing, teaching and scientific research;
※ it integrates six functions of pile, strength, defect, width, depth and pavement bending resistance;
※ semi reflective and semi transparent, high brightness, TFT color LCD screen;
※ full touch screen operation, simple and convenient, stable and reliable;
※ multi channel automatic acquisition, automatic recording of height and sound waveform;
※ the depth recording wheel adopts dust-proof and waterproof design;
※ large memory capacity and working time of more than 10 hours;
※ it can be directly connected to the digital rebound meter probe for ultrasonic rebound comprehensive strength measurement;
※ the U disk is used to transfer data and support software upgrading through the U disk;
※ the special analysis software has powerful functions, and data analysis and processing, report generation, and printing of reports can be easily completed;
※ the transducer spool is designed with a collector ring, and the signal cable can be retracted and retracted freely to prevent the cable from being twisted;
※ the Chinese and English interfaces can be switched freely, making it more convenient for foreign customers to use.
Specification
|
Product Model
|
BTU960
|
|
Master control unit
|
Buit-in A9 industrial control motherboard
|
|
Display
|
10.1 inch, high brightness, TFT color LCD capacitive screen
|
|
Operational mode
|
Touch screen
|
|
Storage mode
|
Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk
|
|
Data transmission mode
|
Wireless Cloud Transport(Options)
|
|
Acquisition mode
|
Synchronous continuous rapid acquisition
|
|
One-time section mumber
|
6
|
|
Channel number
|
4（transmit and receive）
|
|
Trigger mode
|
Signal triggering
|
|
Sampling period(μs)
|
0.05~409.6 Multistage Options
|
|
Acoustic time accuracy(μs)
|
0.05
|
|
Acoustic time range(μs)
|
+1677700
|
|
Width measurement function
|
Range: 0~10mm Accuracy: 0.01mm
|
|
Dynamic range(dB)
|
146
|
|
Bandwidth(kHz)
|
1~500
|
|
Receiving sensitivity(μV)
|
≤10
|
|
Emission voltage(V)
|
65, 250, 500 and 1000 gears adjustable
|
|
Communication
|
UBS, Bluetooth, Wifi
|
|
Working hours(h)
|
More than 8
|
|
Power supply mode
|
Built-in lithium battery
External 220V~ 16V AC/CD |
|
Working environment
|
Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%
|
|
Host size(mm)
|
300*200*55
|
