Quick Details
-
Rated Loading Capacity:
-
5000kg
-
Rated Lifting Moment:
-
6 t.m
-
Max. Lifting Height:
-
16.13 m
-
Place of Origin:
-
China
-
Brand Name:
-
UCARRY
-
Product name:
-
Truck Crane Machine
-
Keywords:
-
Crane
-
Engine:
-
Yammar
-
Function:
-
Handing Goods Easily
-
MOQ:
-
1 UNIT
-
After-sales Service Provided:
-
Spare Parts
-
Color:
-
Customers Requirements
-
Certification:
-
CE
Quick Details
-
Weight (KG):
-
10910
-
Marketing Type:
-
New Product 2023
-
Application:
-
Construction, Building\Agriculture
-
Rated Loading Capacity:
-
5000kg
-
Rated Lifting Moment:
-
6 t.m
-
Max. Lifting Height:
-
16.13 m
-
Place of Origin:
-
China
-
Brand Name:
-
UCARRY
-
Product name:
-
Truck Crane Machine
-
Keywords:
-
Crane
-
Engine:
-
Yammar
-
Function:
-
Handing Goods Easily
-
MOQ:
-
1 UNIT
-
After-sales Service Provided:
-
Spare Parts
-
Color:
-
Customers Requirements
-
Certification:
-
CE
Good quality rough terrain mobile hydraulic truck cranes engine crane machine claw crane for sale
Specification
|
Specifications
|
|
|
|
Product name
|
Crane
|
|
|
Model
|
URC5C
|
|
|
Dimension
|
5130*2320*2795 mm
|
|
|
Total weight
|
10910 kg
|
|
|
Size
|
|
|
|
Crawler length
|
2915 mm
|
|
|
Track base
|
2335 mm
|
|
|
Ground clearance of platform
|
751 mm
|
|
|
Tail swing radius
|
1471 mm
|
|
|
Chassis width
|
2320 mm
|
|
|
Track width
|
450 mm
|
|
|
Min.ground clearance
|
343 mm
|
|
|
Track height
|
650 mm
|
|
|
The top of the operating room is off the ground
|
2795 mm
|
|
|
Engine
|
|
|
|
Brand
|
YANMAR
|
|
|
Operation type
|
Water cooled / Turbol
|
|
|
Displacement
|
3.319 L
|
|
|
Power / Speed
|
46.2 KW/2200 rpm
|
|
|
Parameter
|
|
|
|
Max.lifting load
|
5 t
|
|
|
Max.torque of basic boom
|
10.5 t.m
|
|
|
Max.lifting force of full extending boom
|
6 t.m
|
|
|
Length of basic boom
|
4.63 m
|
|
|
Longest arm length
|
15.63 m
|
|
|
Max.lifting height of the basic arm
|
5.3 m
|
|
|
Max.lifting height of the longest arm
|
16.13 m
|
|
|
Max.grade ability
|
36.4%
|
|
|
Ground pressure
|
0.05 Mpa
|
|
|
Working range
|
|
|
|
Boom rising / descending time
|
11/9 s
|
|
|
Boom extending / retracting time
|
23/39 s
|
|
|
Slewing speed
|
3 rpm
|
|
|
Max.line speed
|
110 m/min
|
|
|
Traveling speed
|
3.8 km/h
|
|
|
Micro-traveling speed
|
0.25 km/h
|
|
