Quick Details
-
Brand Name:
-
DOM
-
Motor Power:
-
40kw
-
Charging Capacity:
-
1500L
-
Reclaiming capacity:
-
1000L
-
Speed of Mixing Drum:
-
14r/min
-
Water Supply Mode:
-
Auto
-
Working Cycle Period:
-
30s
-
Discharge Way:
-
Hydraulic
-
Outline Dimension:
-
2981*2602*2217mm
-
Weight (KG):
-
500 kg
-
Mixing Star* Mixing Blade (Qty):
-
2*4
-
Side Scraper/ Discharge Scraper (Qty):
-
1/1
-
Weighing:
-
Provided
-
Weight:
-
5800KG
-
lifting device:
-
Opitional
-
Transport:
-
Container
-
Hydraulic Discharging Power (Kw):
-
3kw
-
Keywords:
-
mixer motor
-
Certificate:
-
CE ISO
-
After Warranty Service:
-
Field maintenance and repair service
Quick Details
-
Mixing Power:
-
37KW
-
Productivity:
-
50L to 4000L
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
DOM
-
Motor Power:
-
40kw
-
Charging Capacity:
-
1500L
-
Reclaiming capacity:
-
1000L
-
Speed of Mixing Drum:
-
14r/min
-
Water Supply Mode:
-
Auto
-
Working Cycle Period:
-
30s
-
Discharge Way:
-
Hydraulic
-
Outline Dimension:
-
2981*2602*2217mm
-
Weight (KG):
-
500 kg
-
Mixing Star* Mixing Blade (Qty):
-
2*4
-
Side Scraper/ Discharge Scraper (Qty):
-
1/1
-
Weighing:
-
Provided
-
Weight:
-
5800KG
-
lifting device:
-
Opitional
-
Transport:
-
Container
-
Hydraulic Discharging Power (Kw):
-
3kw
-
Keywords:
-
mixer motor
-
Certificate:
-
CE ISO
-
After Warranty Service:
-
Field maintenance and repair service
|
technical parameter
|
|
Item
|
MP50
|
MP100
|
MP250
|
MP330
|
MP500
|
MP750
|
|
Out capacity(L)
|
50
|
100
|
250
|
330
|
500
|
750
|
|
Input Capacity(Kg)
|
75
|
150
|
375
|
500
|
750
|
1125
|
|
Out mass(L)
|
120
|
240
|
600
|
800
|
1200
|
1800
|
|
Mixing Power(Kw)
|
3
|
5.5
|
11
|
15
|
18.5
|
30
|
|
Mixing Star*Mixing Blade(Qty)
|
1/2
|
1/2
|
1/2
|
1/2
|
1/2
|
1/3
|
|
Side Scraper/Discharge Scraper(Qty)
|
1/1
|
1/1
|
1/1
|
1/1
|
1/1
|
1/1
|
|
Weight(Kg)
|
700
|
1100
|
1500
|
2000
|
2400
|
3900
|
|
Lifting power(Kw)
|
-
|
2.2
|
3
|
4
|
4
|
7.5
|
|
Dimension(mm)
|
950x790x1200
|
1670x1460x1450
|
1860x1650x1780
|
1870x1870x1855
|
2230x2080x1880
|
2890x2340x2195
|
|
Item
|
MP1000
|
MP1500
|
MP2000
|
MP2500
|
MP3000
|
MP4000
|
|
Out capacity(L)
|
1000
|
1500
|
2000
|
2500
|
3000
|
4000
|
|
Input Capacity(Kg)
|
1500
|
2250
|
3000
|
3750
|
4500
|
6000
|
|
Out mass(L)
|
2400
|
3600
|
4800
|
6000
|
7200
|
9600
|
|
Mixing Power(Kw)
|
37
|
55
|
75
|
90
|
110
|
160
|
|
Mixing Star*Mixing Blade(Qty)
|
2/4
|
2/4
|
3/6
|
3/6
|
3/9
|
3/9
|
|
Side Scraper/Discharge Scraper(Qty)
|
1/1
|
1/1
|
1/2
|
1/2
|
1/2
|
1/2
|
|
Discharging Power(KW)
|
3
|
3
|
4
|
4
|
4
|
4
|
|
Weight(Kg)
|
6200
|
7700
|
9500
|
11000
|
12000
|
16500
|
|
Lifting power(Kw)
|
11
|
15
|
22
|
30
|
37
|
-
|
|
Dimension(mm)
|
2890x
2602x
2220
|
3230x
2902x
2470
|
3625x
3230x
2630
|
3900x3550x2695
|
3900x3550x2975
|
4560x4150x3105
|
|
|
Main products
Mobile Concrete Batching Plant
Container cement Silo
Stackable Cement Silo
Planetary Mixer
Twin Shafts Mixer
Mobile Cement Silo
Bolted Cement Silo HZS type
Batching Plant
Big Bag Cement silo
1.Are you original manufacturer?
A: Yes. We SDDOM are factory in construction machinery in China with whole concrete mixing / silo storage convey
products you need.
2.What kind terms of payment can be accepted?
A: Normally we can work on T/T term or L/C term.
3.Which incoterm 2010 terms can we work?
A: Normally we work on EXW, FOB, CFR, CIF, DAP
4.What about the delivery time?
A: 7-30 days after receiving the deposit.
5.What about the warranty time?
A: 12 months after delivery generally.
6.What about the MOQ?
2.What kind terms of payment can be accepted?
A: Normally we can work on T/T term or L/C term.
3.Which incoterm 2010 terms can we work?
A: Normally we work on EXW, FOB, CFR, CIF, DAP
4.What about the delivery time?
A: 7-30 days after receiving the deposit.
5.What about the warranty time?
A: 12 months after delivery generally.
6.What about the MOQ?
A: MOQ 1 unit
