Quick Details
-
Panel Size:
-
1000x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
KS-GLS-PH3.91-7.8
-
use:
-
led video wall
-
Pixel Pitch:
-
3.91-7.8MM, 3.91mm
-
Specification:
-
Transparent led display
-
Display Function:
-
Video
-
Screen Dimension:
-
Customized Size
-
Pixel Resolution:
-
32512dots/sq.m
-
LED type:
-
SMD1921
-
Brightness:
-
4500nits
-
Power consumption/SQ.M:
-
MAX 700W; AVE220W
-
Warranty:
-
2 years
-
Module size:
-
500x250mm
-
Transparent rate:
-
85%
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
KENSUN
-
Color:
-
Full color
-
Panel Size:
-
1000x500mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
KS-GLS-PH3.91-7.8
-
use:
-
led video wall
-
Pixel Pitch:
-
3.91-7.8MM, 3.91mm
-
Specification:
-
Transparent led display
-
Display Function:
-
Video
-
Screen Dimension:
-
Customized Size
-
Pixel Resolution:
-
32512dots/sq.m
-
LED type:
-
SMD1921
-
Brightness:
-
4500nits
-
Power consumption/SQ.M:
-
MAX 700W; AVE220W
-
Warranty:
-
2 years
-
Module size:
-
500x250mm
-
Transparent rate:
-
85%
Indoor P3.91-7.8 transparent led display
LED transparent display screen is becoming more and more popular, and market share and customer awareness are rising. However,there are still many customers who don't know much, are still waiting to see or don't know how to implant LED transparent screens into their own scene designs.
Feature and advantage
Feature and advantage
1. High transparency effect of transparent LED display
Due to the difference in point spacing, the light transmittance of the transparent LED display can reach about 50-90%. The perspective effect allows the glass to retain the function of lighting perspective, and the LED lights can hardly be seen from a distance, so that the lighting of the glass curtain wall is not affected.
2. The transparent LED display occupies a small space and is light in weight.
Due to the difference in point spacing, the light transmittance of the transparent LED display can reach about 50-90%. The perspective effect allows the glass to retain the function of lighting perspective, and the LED lights can hardly be seen from a distance, so that the lighting of the glass curtain wall is not affected.
2. The transparent LED display occupies a small space and is light in weight.
The thickness of the main board of the screen is only 10mm. After installing the transparent LED display, it takes up almost no space and does not interfere with other facilities or structures near the glass curtain wall. The LED transparent screen is extremely light in weight, and the load requirement of the rear glass curtain wall installed on it changes very little.
3. The transparent LED display only needs a simple steel frame structure, which saves a lot of costs
The product is light in weight, easy to install, and does not require complex supporting steel structures, which can save a lot of installation costs.
4. The maintenance of the transparent LED display is convenient and fast
Indoor maintenance is fast and safe, saving manpower and material resources.
4. The maintenance of the transparent LED display is convenient and fast
Indoor maintenance is fast and safe, saving manpower and material resources.
5. Transparent LED display saves the lighting cost of the building
If the LED glass curtain wall display (transparent screen) is installed, a large part of the exterior wall lighting can be saved.LED screens are more attractive, which can save costs and have advertising benefits.
If the LED glass curtain wall display (transparent screen) is installed, a large part of the exterior wall lighting can be saved.LED screens are more attractive, which can save costs and have advertising benefits.
6. Transparent LED display is energy-saving and environmentally friendly
Its own power consumption is small, the average power consumption is less than 280W/sq.m, and it does not require traditional refrigeration systems and air conditioners to dissipate heat.
7. The transparent LED display is easy to controlled
It can be connected to a computer, graphics card, and remote transceiver through a network cable, or it can be controlled wireless through a remote cluster to change the display content at any time.
Its own power consumption is small, the average power consumption is less than 280W/sq.m, and it does not require traditional refrigeration systems and air conditioners to dissipate heat.
7. The transparent LED display is easy to controlled
It can be connected to a computer, graphics card, and remote transceiver through a network cable, or it can be controlled wireless through a remote cluster to change the display content at any time.
Tech specifications
|
Pixel Pitch
|
3.9-7.8mm
|
|
Model
|
P3.9-7.8 indoor full color led module
|
|
Pixel Configuration
|
SMD19211R1G1B
|
|
Module Resolution
|
128dotsX32dots
|
|
Module Pixles
|
4096dots
|
|
Module Size
|
500mm(W) x250mm(H)
|
|
Cabinet size
|
500x1000mm or 1000x1000mm
|
|
Voltage
|
AC90-240V
|
|
Cabinet weight
|
14kg/sq.m
|
|
Power Consumption/SQ.M
|
MAX700W; AVE 220W
|
|
Waterproof
|
IP45
|
|
Serviceability
|
Rear/Front service
|
|
Viewing Angle
|
H:140° V:120°
|
|
Brightness
|
≥2000 cd/sq.m
|
|
Optimal Viewing Distance
|
≥3.91m
|
|
Drive Method
|
1/16 scan
|
|
Contrast ratio
|
10000:01:00
|
|
Operating temperature
|
-20ºC to +60ºC
|
|
Operating humidity
|
20% to 90%
|
|
Lifetime (50% brightness)
|
100,000 hours
|
|
Refresh Rate
|
≥ 1920 Hz
|
|
Operating Platform
|
WINDOWS(WIN98,WIN2000, WIN XP)
|
