wood pellet machine for alfalfa pellet making maker is a kind of biomass energy pretreatment equipment. It mainly uses biomass from agriculture and forestry processing such as wood chips, straw, rice husks, bark and other biomass as raw materials. Through pretreatment and processing, it is solidified into high-density particulate fuel. Biomass pellet machine is divided into flat-die biomass pellet machine and ring-die biomass pellet machine.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Yibao
-
Voltage:
-
380 v
-
Dimension(L*W*H):
-
1400*750*1550 mm
-
Motor Power (Kw):
-
55kw
-
Power (kW):
-
55 kw
-
Weight (KG):
-
3200 KG
-
Name:
-
Wood Pellet Making Machine
-
Application:
-
Make Biomass Pellets
-
Product name:
-
wood pellet mill flat die wood pellet machine wood pellet hammer mill
-
Capacity:
-
1-1.5t/h
-
Type:
-
Vertical Rind Die Pellet Mill
-
Color:
-
Clients' Requirement
-
Raw material:
-
Sawdust\straw\rice Husk\wood Waste
-
Keywords:
-
Pellet Making Plant
-
Pellet size:
-
4-12 mm
-
Moisture of raw material:
-
15-20%
Quick Details
-
Pellet Diameter (mm):
-
4 - 12
-
Output (kg/h):
-
500 - 3500 kg/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yibao
-
Voltage:
-
380 v
-
Dimension(L*W*H):
-
1400*750*1550 mm
-
Motor Power (Kw):
-
55kw
-
Power (kW):
-
55 kw
-
Weight (KG):
-
3200 KG
-
Name:
-
Wood Pellet Making Machine
-
Application:
-
Make Biomass Pellets
-
Product name:
-
wood pellet mill flat die wood pellet machine wood pellet hammer mill
-
Capacity:
-
1-1.5t/h
-
Type:
-
Vertical Rind Die Pellet Mill
-
Color:
-
Clients' Requirement
-
Raw material:
-
Sawdust\straw\rice Husk\wood Waste
-
Keywords:
-
Pellet Making Plant
-
Pellet size:
-
4-12 mm
-
Moisture of raw material:
-
15-20%
Introduction to domestic wood pellet mills
.
|
Model
|
YB-210
|
YB-250
|
YB-300
|
YB-350
|
YB-400
|
|
Power(KW)
|
7.5
|
15
|
22
|
30
|
37
|
|
capacity(h/kg)
|
80-100
|
100-200
|
200-300
|
300-400
|
400-600
|
|
Dimension(MM)
|
1100*400*980
|
1100*400*980
|
1280*560*1200
|
1300*530*1290
|
1390*650*1290
|
|
weight
|
280
|
400
|
800
|
900
|
1000
|
Wood pellet mill
Wood sawdust pellet machine exported wood pellet machine new genaration pellet mill is a kind of biomass energy saving equipment. It mainly uses biomass from agriculture and forestry processing such as wood chips, straw, rice husks,bark and other biomass as raw materials. Through pretreatment and processing, the wood pellet making machine is solidified into high-density particulate fuel.Biomass pellet machine is divided into flat-die biomass pellet machine and ring-die biomass pellet machine.biomass pellet making machine biomass wood pelleting machine
Pellet fuel is produced by pressing raw materials such as wood chips and straw under pressure at normal temperature using a roller and a ring die. The density of raw materials is generally about 0.6-0.8, and the density of particles after molding is greater than 1.1, which is extremely convenient to transport and store. At the same time, its combustion performance is greatly improved,reducing human dependence on petrochemical energy and atmospheric emissions.
biomass pellet making machine biomass wood pelleting machine
The use of biomass fuels is a new type of bio-energy. It can replace wood, raw coal, fuel oil, liquefied gas, etc. It is widely used, such as:
1. Civil heating and domestic energy: high fuel utilization and easy storage.
2. Biomass industrial boiler: as the main fuel for industrial boilers, replacing coal combustion, reducing atmospheric emissions and pollution.
3. Power generation: It can be used as a fuel for thermal power generation.
1. Civil heating and domestic energy: high fuel utilization and easy storage.
2. Biomass industrial boiler: as the main fuel for industrial boilers, replacing coal combustion, reducing atmospheric emissions and pollution.
3. Power generation: It can be used as a fuel for thermal power generation.
1. It adopts high-precision involute cylindrical helical gear direct transmission, with a transmission efficiency of more than 98%, which is 20 ~ 25% higher than the production efficiency of traditional belt granulators;
biomass pellet making machine biomass wood pelleting machine
2. The gear teeth of the transmission gear are normalized heat-treated after water forging to increase the hardness of the tooth surface. The tooth surface is treated with carburizing. The depth of the carburized layer is 24mm to enhance the wear resistance and prolong the service life of the parts. Silent fine grinding repair process, making the operation quieter and more stable;
3. The bearings used in the particle forming system are all high-quality silent bearings, and the thin oil circulation cooling and lubrication system is added to ensure longer bearing life and safer operation;
4. Press roller automatic adjustment function: the principle of bidirectional rotation of the thrust bearing is used to automatically adjust the pressure angle, so that the material is not crowded, and the machine is not stuffy, ensuring the stability of the material forming;
biomass pellet making machine biomass wood pelleting machine
The use of biomass fuels is a new type of bio-energy. It can replace wood, raw coal, fuel oil, liquefied gas, etc. It is widely used, such as:
1. Civil heating and domestic energy: high fuel utilization and easy storage.
2. Biomass industrial boiler: as the main fuel for industrial boilers, replacing coal combustion, reducing atmospheric emissions and pollution.
3. Power generation: It can be used as a fuel for thermal power generation.
1. Civil heating and domestic energy: high fuel utilization and easy storage.
2. Biomass industrial boiler: as the main fuel for industrial boilers, replacing coal combustion, reducing atmospheric emissions and pollution.
3. Power generation: It can be used as a fuel for thermal power generation.
