Quick Details
-
Table Travel (Z) (mm):
-
1600 mm
-
Max. Table Load(kg):
-
10000
-
Travel (W-axis) (mm):
-
800 mm
-
Positioning Accuracy (X axis) mm:
-
0.02
-
Positioning Accuracy (Y axis) mm:
-
0.02
-
Positioning Accuracy (Z axis) mm:
-
0.02
-
Range of Spindle Speed(r.p.m):
-
2000 r.p.m
-
Spindle Motor Power(kW):
-
22/30
-
Production Capacity:
-
Other
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
DMTG
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
6700*7800*4700
-
Weight (T):
-
5 T
-
Product name:
-
Boring Machine Tool
-
Functions:
-
Cnc Boring Milling Machine
-
Application:
-
Repair Auto Motorcycle Engine Block
-
Keyword:
-
Horizontal Engine Block Boring Milling Machine
-
Product type:
-
Horizontal Boring Milling Machine
-
Machine type:
-
Horizontal Milling
-
Precision:
-
High Precision
-
Cnc machine center:
-
Plate Boring Machine
-
Usage:
-
Multi Function Metal Processing
-
Item name:
-
Horizontal boring machine for sale
Quick Details
-
Table Size (mm):
-
1600*2000
-
Table Travel (X) (mm):
-
2000 mm
-
Table Travel (Y) (mm):
-
1600 mm
-
Table Travel (Z) (mm):
-
1600 mm
-
Max. Table Load(kg):
-
10000
-
Travel (W-axis) (mm):
-
800 mm
-
Positioning Accuracy (X axis) mm:
-
0.02
-
Positioning Accuracy (Y axis) mm:
-
0.02
-
Positioning Accuracy (Z axis) mm:
-
0.02
-
Range of Spindle Speed(r.p.m):
-
2000 r.p.m
-
Spindle Motor Power(kW):
-
22/30
-
Production Capacity:
-
Other
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
DMTG
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
6700*7800*4700
-
Weight (T):
-
5 T
-
Product name:
-
Boring Machine Tool
-
Functions:
-
Cnc Boring Milling Machine
-
Application:
-
Repair Auto Motorcycle Engine Block
-
Keyword:
-
Horizontal Engine Block Boring Milling Machine
-
Product type:
-
Horizontal Boring Milling Machine
-
Machine type:
-
Horizontal Milling
-
Precision:
-
High Precision
-
Cnc machine center:
-
Plate Boring Machine
-
Usage:
-
Multi Function Metal Processing
-
Item name:
-
Horizontal boring machine for sale
DMTG Low Price CNC Boring Milling Machine CNC Lathe Milling Lathe Machine Small CNC Metal Processing Machine
|
ITEM
|
UNIT
|
PARAMETER
|
|
Table size
|
mm
|
1400*1600(1600*1800)
|
|
Max. load on the table
|
kg
|
10000
|
|
Worktable and slot
|
|
28*9
|
|
Dia. of spindle
|
mm
|
130
|
|
Speed of spindle
|
r/min
|
10-2000
|
|
Max. torque
|
nm
|
2500/3000
|
|
Distance between spindle center and table top
|
mm
|
100-1700
|
|
Min. distance between spindle end and table
|
mm
|
850 Zero position of spindle(1050/2000 worktable width/10T)
|
|
X/Y/Z /W/travel
|
mm
|
2000/1600/1600/800
|
|
Feed speed of X/Y/Z
|
mm/min
|
1-6000
|
|
Power of main motor
|
kw
|
22/30
|
