Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUNKET
-
Model Number:
-
SKT5KW-ON
-
Output Frequency:
-
50/60HZ
-
Work Time (h):
-
Depend On Sunshine Duration
-
Product Name:
-
inverter solar power system
-
DC Cable:
-
4mm2
-
DC Disconnect Switch:
-
1000VDC 16A
-
On Grid Inverter:
-
5KW
-
Connector:
-
PV connector
-
Online Monitoring:
-
Wifi/Lan/GPRS
-
Mounting System:
-
Pitched Roof For Standards
-
Output Voltage (V):
-
208V/230V/240V
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon
-
Battery Type:
-
NONE
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUNKET
-
Model Number:
-
SKT5KW-ON
-
Output Frequency:
-
50/60HZ
-
Work Time (h):
-
Depend On Sunshine Duration
-
Product Name:
-
inverter solar power system
-
DC Cable:
-
4mm2
-
DC Disconnect Switch:
-
1000VDC 16A
-
On Grid Inverter:
-
5KW
-
Connector:
-
PV connector
-
Online Monitoring:
-
Wifi/Lan/GPRS
-
Mounting System:
-
Pitched Roof For Standards
-
Output Voltage (V):
-
208V/230V/240V
Warranty
Hybrid Solar Energy System Also Named On&Off Grid Solar Energy System. It has the feature and function of both on grid and off grid solar energy system. If you have a set of hybrid solar energy system, you could use electricity from solar panel in the daytime when sun is good, you could use electricity stored in battery bank in the evening or on rainy days.
Technical Specifications
|
Hybrid Solar System with LV Battery Solution
|
|
|
|
|
|
|
|
|||||||
|
5/6KW Hybrid Solar Power System Components List
|
|
|
|
8KW Hybrid Solar Power System Components List
|
|
|
|
|||||||
|
Item
|
Model
|
Description
|
Quantity
|
Item
|
Model
|
Description
|
Quantity
|
|||||||
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
16 pc
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
22 pc
|
|||||||
|
2
|
Hybrid Inverter
|
5/6KW, 230V/50Hz
|
1 pc
|
2
|
Hybrid Inverter
|
8KW, 380V/50Hz
|
1 pc
|
|||||||
|
3
|
Lithium Battery
|
Total LV 5KWH or customized
|
1 Set
|
3
|
Lithium Battery
|
Total LV 10KWH or customized
|
1 Set
|
|||||||
|
4
|
Cable
|
4mm2
|
200 meter
|
4
|
Cable
|
4mm2
|
200 meter
|
|||||||
|
5
|
Connector
|
MC4 Connectors
|
8 Pairs
|
5
|
Connector
|
MC4 Connectors
|
10 Pairs
|
|||||||
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
|||||||
|
10KW Hybrid Solar Power System Components List
|
|
|
|
12KW Hybrid Solar Power System Components List
|
|
|
|
|||||||
|
Item
|
Model
|
Description
|
Quantity
|
Item
|
Model
|
Description
|
Quantity
|
|||||||
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
26 pc
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
30 pc
|
|||||||
|
2
|
Hybrid Inverter
|
10KW, 380V/50Hz
|
1 pc
|
2
|
Hybrid Inverter
|
12KW, 380V/50Hz
|
1 pc
|
|||||||
|
3
|
Lithium Battery
|
Total LV 10KWH or customized
|
1 Set
|
3
|
Lithium Battery
|
Total LV 10KWH or customized
|
1 Set
|
|||||||
|
4
|
Cable
|
4mm2
|
400 meters
|
4
|
Cable
|
4mm2
|
400 meters
|
|||||||
|
5
|
Connector
|
MC4 Connectors
|
12 Pairs
|
5
|
Connector
|
MC4 Connectors
|
16 Pairs
|
|||||||
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
|||||||
|
Hybrid Solar System with HV Battery Solution
|
|
|
|
|
|
|
|
|||||||
|
6KW Hybrid Solar Power System Components List
|
|
|
|
8KW Hybrid Solar Power System Components List
|
|
|
|
|||||||
|
Item
|
Model
|
Description
|
Quantity
|
Item
|
Model
|
Description
|
Quantity
|
|||||||
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
16 pc
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
22 pc
|
|||||||
|
2
|
Hybrid Inverter
|
6KW, 380V/50Hz
|
1 pc
|
2
|
Hybrid Inverter
|
8KW, 380V/50Hz
|
1 pc
|
|||||||
|
3
|
Lithium Battery
|
Total 12kWh or customzied
|
1 Set
|
3
|
Lithium Battery
|
Total 12kWh or customzied
|
1 Set
|
|||||||
|
4
|
Cable
|
4mm2
|
200 meter
|
4
|
Cable
|
4mm2
|
200 meter
|
|||||||
|
5
|
Connector
|
MC4 Connectors
|
8 Pairs
|
5
|
Connector
|
MC4 Connectors
|
10 Pairs
|
|||||||
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
|||||||
|
10KW Hybrid Solar Power System Components List
|
|
|
|
12KW Hybrid Solar Power System Components List
|
|
|
|
|||||||
|
Item
|
Model
|
Description
|
Quantity
|
Item
|
Model
|
Description
|
Quantity
|
|||||||
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
26 pc
|
1
|
Solar Panel
|
All Black/Silver Mono 410W
|
30 pc
|
|||||||
|
2
|
Hybrid Inverter
|
10KW, 380V/50Hz
|
1 pc
|
2
|
Hybrid Inverter
|
12KW, 380V/50Hz
|
1 pc
|
|||||||
|
3
|
Lithium Battery
|
Total 12kWh or customzied
|
1 Set
|
3
|
Lithium Battery
|
Total 12kWh or customzied
|
1 Set
|
|||||||
|
4
|
Cable
|
4mm2
|
200 meter
|
4
|
Cable
|
4mm2
|
200 meter
|
|||||||
|
5
|
Connector
|
MC4 Connectors
|
12 Pairs
|
5
|
Connector
|
MC4 Connectors
|
16 Pairs
|
|||||||
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
6
|
Mounting Support
|
Ground/Roof Mounted
|
1 Set
|
|||||||
|
Kindly Reminder: The Above System Configuration For Initial Designing, The System Configuration Are Subject to Changing Depends on Your Final Installation Conditions and Requirements.
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|||||||
Product Details
All Black 410W Solar Panels
Maximum Power- Pmax: 410W
Open Circuit Voltage - Voc:37.32V
Short- Circuit Current - Isc:13.95A
Voltage at Pmax -Vmp：31.45V
Current at Pmax - Imp：13.04A
Module Efficiency - ηm：21%
Hybrid Solar Inverter
Colorful touch LCD, IP65 protection degree
DC couple and AC couple to retrofit existingsolar system
Max. 16pcs parallel for on-grid and off-gridoperation
Support multiple batteries parallel
Max. charging/discharging current of 140A
6 time periods for battery charging/discharging
Support storing energy from diesel generator
Up to 6000 + cycle life Wall mounted /stack mounted to choose, simplyconnecting to inverter Battery module is scalable for any
larger storage system. Battery modular built in high quality BMS Lithium iron phosphate battery cell, safe and efficient
larger storage system. Battery modular built in high quality BMS Lithium iron phosphate battery cell, safe and efficient
Mounting Rail & Rail Splice Kit Mid & End Clamps: 35,40,45,50mmL Foot Asphalt Shingle Moount & HangerBolt Optiona Cable clip & Tie
OptionaGround clip & Lugs Optional Lifetime: 25 Years
OptionaGround clip & Lugs Optional Lifetime: 25 Years
1.AC Cable
2DC Switches
3. AC Breaker
4.AC/DC Combine box
5.PV Cable
