Quick Details
-
Place of Origin:
-
China
-
CPU:
-
Xeon processor E5-2600 v3/v4
-
Socket:
-
LGA-2011-3
-
Memory Type:
-
DDR4
-
Chipset:
-
Intel C612
-
IPMI:
-
1 RJ45
-
Network Controllers:
-
Dual LAN RJ45
-
PCI-E:
-
6 PCI-E
Quick Details
-
Type:
-
Rack
-
Processor Type:
-
E5-2600 v3/v4
-
Model Number:
-
R2002-ET26
-
Place of Origin:
-
China
-
CPU:
-
Xeon processor E5-2600 v3/v4
-
Socket:
-
LGA-2011-3
-
Memory Type:
-
DDR4
-
Chipset:
-
Intel C612
-
IPMI:
-
1 RJ45
-
Network Controllers:
-
Dual LAN RJ45
-
PCI-E:
-
6 PCI-E
Products Description
|
Product parameter
|
|
|
|
|
||||
|
|
* Intel® Xeon® processor E5-2600 v3, Intel® Xeon® processor E5-2600 v4
* Dual Socket LGA-2011-3 (Socket R3) supported, CPU TDP support Up to 145W TDP, 1 QPI up to 9.6 GT/s |
|
|
|
||||
|
Chipset
|
* Intel® C612
|
|
|
|
||||
|
Memory
|
* 8 DIMM slots, Up to * 512GB Registered ECC RDIMM, DDR4-2400MHzUp to 1TB 3DS ECC LRDIMM
|
|
|
|
||||
|
On-Board Devices
|
* SATA3 (6Gbps); RAID 0/1/5/10 support
|
|
|
|
||||
|
Drive Bays / Storage
|
* 8x 3.5"/2.5" hot-swap SATA/SAS drive bays + Rear optional（2x 2.5"）
|
|
|
|
||||
|
Network
|
* 2x 1GbE BaseT with Intel® i210，1x RJ45 IPMI
|
|
|
|
||||
|
IPMI
|
* IPMI 2.0
|
|
|
|
||||
|
Video
|
* 1 VGA port(s)
|
|
|
|
||||
|
Expansion Slots
|
* 3 PCI-E 3.0 x8,
* 1 PCI-E 3.0 x16, * 1 PCI-E 3.0 x4 (in x8 slot) * 1 PCI-E 2.0 x4 (in x8 slot) |
|
|
|
||||
|
Power Supply
|
* 550～2000W Redundant Platinum Level power supplies
|
|
|
|
||||
|
Dimension
|
650*438*88mm（D*W*H）
|
|
|
|
||||
|
Operating Environment
|
* Operating Temperature:10°C ~ 35°C (50°F ~ 95°F)
* Non-operating Temperature:-40°C to 60°C (-40°F to 140°F) * Operating Relative Humidity:8% to 90% (non-condensing) * Non-operating Relative Humidity:5% to 95% (non-condensing) |
|
|
|
||||
