Quick Details
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
QXL
-
Model Number:
-
QXCP
Product Overview
|
Contact capacity
|
AC250V/15A
|
|
Rated Current
|
8A
|
|
Output signal
|
SPST NO / NC
|
|
Operating temperature
|
PP: -10 ~ 80°C, SS304: -10 ~ 180°C
|
|
Weather proof
|
IP68
|
QXCF-B
Features
* Rugged float IP68 enclosure rating
* Neoprene specified cable, silicon cable selectable
* Construct simple, maintenance free, installation easy
Principle
One-step Injection Molding
QXCFP, QXCFS Type float switch make use of micro switch as contact component. The switch will have ON or OFF contact signal output when the angle is larger than 28 Degree
QXCFS Type float switch make use of mercury switch as contact component. When liquid lift up to contact float, the float will have variable angles. The switch will have ON or OFF contact signal output when the angle is larger than 10 Degree.
Features
* Rugged float IP68 enclosure rating
* Neoprene specified cable, silicon cable selectable
* Construct simple, maintenance free, installation easy
Principle
One-step Injection Molding
QXCFP, QXCFS Type float switch make use of micro switch as contact component. The switch will have ON or OFF contact signal output when the angle is larger than 28 Degree
QXCFS Type float switch make use of mercury switch as contact component. When liquid lift up to contact float, the float will have variable angles. The switch will have ON or OFF contact signal output when the angle is larger than 10 Degree.
Rubber float level switch cable PP water level float switch float level sensor tanki bahan dengan mechanic system
