Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Usuage:
-
Gas-liquid dual-use type
-
Output:
-
Reed switch, capacity 24VDC/250VAC,100mA
-
Accuracy:
-
±5 total range
-
Hysteresis:
-
Mix 0.6L /min depending on the switching point
-
Principle:
-
Mechanical
-
Withstand pressure:
-
10bar(plastic), 50bar (aluminum), 100bar (stainless steel)
-
Average pressure loss:
-
0.3bar (at 25L/min)
-
Medium temperature:
-
Max100°C
-
Protection gradel:
-
IP65
Quick Details
-
Brand Name:
-
KATU
-
Model Number:
-
FC210
-
Type:
-
flow switch, Flow switch
-
Place of Origin:
-
Jiangsu, China
-
Usuage:
-
Gas-liquid dual-use type
-
Output:
-
Reed switch, capacity 24VDC/250VAC,100mA
-
Accuracy:
-
±5 total range
-
Hysteresis:
-
Mix 0.6L /min depending on the switching point
-
Principle:
-
Mechanical
-
Withstand pressure:
-
10bar(plastic), 50bar (aluminum), 100bar (stainless steel)
-
Average pressure loss:
-
0.3bar (at 25L/min)
-
Medium temperature:
-
Max100°C
-
Protection gradel:
-
IP65
|
Product name
|
FC210 Wholesale G1/2" plastic water flow switch/piston flow sensor SS304 material flow switch for water pump
|
|
|
|
|||
|
Keyword-1
|
flow switch for water pump
|
|
|
|
|||
|
Keyword-2
|
piston flow sensor
|
|
|
|
|||
|
Keyword-3
|
water flow switch
|
|
|
|
|||
|
Accuracy:
|
±5 total range
|
|
Hysteresis:
|
Depends on the switch point, minimum 0.6L/min
|
|
Switch setting scale:
|
When the medium is water, the temperature is 20°C, (calibrated in the horizontal installation state. The
installation position, medium and temperature changes will slightly affect the switch value) |
|
LED display:
|
DC power supply LED display switch status, AC no LED display
|
|
Wiring mode:
|
M12 connector
|
|
Output:
|
Reed switch, capacity 24VDC/250VAC, 100mA
|
|
Pressure resistance:
|
10bar (plastic), 50bar (aluminum type), 100bar (stainless steel)
|
|
Average pressure loss:
|
0.3bar (at 25L/min)
|
|
Medium temperature:
|
maximum 100°C
|
|
Protection level:
|
IP65
|
Principle characteristics
Online installation, mechanical flow switch, used for liquid or gaseous media. Sturdy plastic, aluminum or stainless steel housing is available. Very small pressure loss, good repeatability, anti-fouling ability, mechanical part and electronic part are completely isolated, suitable for small flow economical type. With switch setting scale, users don't need to set it on site. LED display switch status, dual switch output is available for selection.
size
