Quick Details
-
Model Number:
-
AH712
-
Max. Current:
-
10A
-
Item:
-
Analogue Time Switch AH712
-
Operating Voltage:
-
AC230V
-
Frequency:
-
50Hz
-
Ambient temperature:
-
-10 °C ~ +50 °C
-
Width:
-
4 modules
-
Installation type:
-
Front panel installation
-
Power consumption:
-
1.5 VA
-
Type of protection:
-
IP 20
Quick Details
-
Max. Voltage:
-
230VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CNSN
-
Model Number:
-
AH712
-
Max. Current:
-
10A
-
Item:
-
Analogue Time Switch AH712
-
Operating Voltage:
-
AC230V
-
Frequency:
-
50Hz
-
Ambient temperature:
-
-10 °C ~ +50 °C
-
Width:
-
4 modules
-
Installation type:
-
Front panel installation
-
Power consumption:
-
1.5 VA
-
Type of protection:
-
IP 20
Description:
- Analogue time switch
- 1 channel
- Switching status display
- Daily program
- 96 switching segments
- Reliable due to synchronous motor drive
- Shortest switching time: 15 minutes
- Simple summer/winter time correction
- Switch construction:SPDT
Technical Data :
| Operating voltage | 230 V AC |
| Frequency | 50 Hz |
| Width | 4 modules |
| Installation type | Front panel installation |
| Program | Daily program |
|
Max. switching capacity at 250 V AC, cos φ = 1 |
16 A |
|
Max. switching capacity at 250 V AC, cos φ = 0.6 |
4 A |
| Shortest switching time | 15 min |
| Programmable every | 15 min |
| Time accuracy | Synchronised with mains |
| Power consumption | 1.5 VA |
| Type of protection | IP 20 |
| Protection class | II in accordance with EN 60 730-1 |
| Ambient temperature | –10 °C … +50 °C |
Connection Example:
Scale Drawings:
