Quick Details
-
Processor Core:
-
Quad Core
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Riotouch
-
Model Number:
-
OPS
-
Operating System:
-
WIN
-
Chipset Type:
-
H110
-
Product Name:
-
Mini PC Computer
-
Application:
-
Education,Meeting,business
-
Certification:
-
FCC
-
Storage:
-
1*mSATA+1*2.5 Inch SATA HDD
-
USB Port:
-
USB3.0
-
Material:
-
Aluminum Alloy
-
Color:
-
Black
-
Memory Type:
-
DDR4
-
Keywords:
-
PC Mini Computer
-
Generation:
-
13th
Quick Details
-
Use:
-
Educational
-
Hard Drive Type:
-
SSD
-
Video Memory Type:
-
GDDR4
-
Processor Core:
-
Quad Core
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Riotouch
-
Model Number:
-
OPS
-
Operating System:
-
WIN
-
Chipset Type:
-
H110
-
Product Name:
-
Mini PC Computer
-
Application:
-
Education,Meeting,business
-
Certification:
-
FCC
-
Storage:
-
1*mSATA+1*2.5 Inch SATA HDD
-
USB Port:
-
USB3.0
-
Material:
-
Aluminum Alloy
-
Color:
-
Black
-
Memory Type:
-
DDR4
-
Keywords:
-
PC Mini Computer
-
Generation:
-
13th
* JAE 80-pin connection
* Support M.2 SSD Module
* Support M.2 WiFi Module
* Support HDMI2.0 out
|
Model
|
Intel I5-4460 3.2G Hz
|
Intel I5-6400 2.7G Hz
|
Intel I7-8700 3.2G Hz
|
|
Memory
|
4G DDR3 1600MHz
|
8G DDR4 2133MHz
|
8G DDR4 2400MHz
|
|
Storage
|
128G SSD
|
256G SSD
|
256G SSD
|
|
Graphics
|
Intel® HD Graphics
|
Intel® HD Graphics 5series
|
Intel® HD Graphics 5series
|
|
Wireless
|
1x Mini-PCIE WIFI/BT Module
|
1 x M.2 2230 WIFI/BT Module
|
1 x M.2 2230 WIFI/BT Module
|
|
Network
|
Intel Gigabit Ethernet
|
Realtek Gigabit Ethernet
|
Realtek Gigabit Ethernet
|
|
Audio
|
Realtek ALC662 HD Audio IC
|
Realtek ALC662 HD Audio IC
|
Realtek ALC662 HD Audio IC
|
|
Interfaces
Frontside
|
1x USB3.0 Type-A
5x USB2.0 Type-A
1x RJ45 10/100/1000M
1x HDMI 1.4 out, Max.4K/24Hz
1x VGA,Max.1920*1200
1x 3.5mm Line out
1x 3.5mm Mic in
2x WIFI/BT ANT
1x Power button
1x Power LED
1x HDD/SSD LED
|
3x USB3.0 3x USB2.0 Type-A
1 x RJ45 10/100/1000M
1 x HDMI 1.4 out, Max.4K/24Hz
1 x DP1.2 out，Max.4K/60Hz
1 x VGA out （optional）
1 x 3.5mm Line out
1 x 3.5mm Mic in
2 x WIFI/BT ANT
1 x Power button
1 x Power LED
1 x HDD/SSD LED
1 x VGA out (Optional)
|
3 x USB3.0 Type-A
3 x USB2.0 Type-A
1 x RJ45 10/100/1000M
1 x HDMI 1.4 out, Max.4K/30Hz
1 x DP1.2 out，Max.4K/60Hz
1 x VGA out （optional）
1 x 3.5mm Line out
1 x 3.5mm Mic in
2 x WIFI/BT ANT
1 x Power button
1 x Recover button
1 x Power LED
1 x HDD/SSD LED
|
|
JAE 80-pin
|
1x HDMI 1.4 out, 4K/24Hz,
3x USB2.0/3.0
TTL
|
1 x HDMI 1.4 out, 4K/24Hz,
3 x USB2.0/3.0
TTL
|
1 x HDMI 2.0 out, 4K/30Hz,
3 x USB2.0/3.0
TTL
|
|
Power input
|
12-19v DC IN
|
12-19v DC IN
|
12-19v DC IN
|
|
Watchdog
|
Support
|
Support
|
Support
|
|
Material
|
Metal
|
Metal
|
Metal
|
|
Dimensions
|
192(L) x 180(W) x 42(H) mm
|
192(L) x 180(W) x 42(H) mm
|
192(L) x 180(W) x 42(H) mm
|
|
Temperature
|
Operdting -5℃~45℃
Storage -20℃~70℃
|
Operdting -5℃~45℃
Storage -20℃~70℃
|
Operdting -5℃~45℃
Storage -20℃~70℃
|
|
Relative humidity
|
10%~95% （non-condensing）
|
10%~95% （non-condensing）
|
10%~95% （non-condensing）
|
|
Net Weight
|
1.6kg
|
1.5KG
|
1.5kg
|
Riotouch is a professional manufacture in the interactive plat panel and display for almost 10 years.
We have our professional Sales team, strong Design, R&D,After-sale service team, to provide our super value products and service to our customers.
1.Q: Are you a Manufacture?
A: Yes, we are a
Manufacture
, located in Dongguan City, Welcome your visit.
2. Q: what's your product quality control?
A: We have strict
QC
team, production meeting
ISO9001
production system. Our products passed
CE,RoHS,FCC
certification.
3. Q: What's your after-sale service?
A: We can offer 100% guarantee on our product. Our general warranty is 1 year.
If any problems, you will get our reply within 24 hours.
4. Q: What's your MOQ?
A: Generally, our MOQ is
1
pcs. More quantities enjoy better discount.
5. Q: Could you offer the OEM service?
A: Yes, we can provide the
OEM
service if our customer requested.
6. Q: How about the delivery?
A: The delivery would be with in
2-15
days according to the order quantity and size of the items.
7.Q: What are your advantages?
A:1.We're direct
factory
, so customization is availabe accroing to your requirement.
2. We have our strong and professional
R&D
and sales team to serve customer well.
3. Low defectives and timely service. The defectives of our products seldom appear , if any quality problems arise, we give spare part or new replacement free of charge.
