Quick Details
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Egood
-
Model Number:
-
EG
-
Track:
-
Anodized aluminum 6063-T6
-
Carrier materials:
-
Imported POM
-
Main frame:
-
Anodized aluminum 6063-T6
-
Carrier overload:
-
225--1300 kg
-
Partition thickness:
-
65, 80, 100mm
-
Sound insulation:
-
Max 53 db
-
Height:
-
Max 17 meter
-
Rockwool infill:
-
55kg/m3
-
Base board:
-
9/12mm thickness plywood/MDF
-
Finishing option:
-
Melamine ,fabric , leather, HPL, wall paper,etc
Quick Details
-
Door Material:
-
Aluminum Alloy
-
Main Material:
-
Polymer
-
Application:
-
Hotel
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Egood
-
Model Number:
-
EG
-
Track:
-
Anodized aluminum 6063-T6
-
Carrier materials:
-
Imported POM
-
Main frame:
-
Anodized aluminum 6063-T6
-
Carrier overload:
-
225--1300 kg
-
Partition thickness:
-
65, 80, 100mm
-
Sound insulation:
-
Max 53 db
-
Height:
-
Max 17 meter
-
Rockwool infill:
-
55kg/m3
-
Base board:
-
9/12mm thickness plywood/MDF
-
Finishing option:
-
Melamine ,fabric , leather, HPL, wall paper,etc
Product Paramenters
|
Parameter
|
|
|
|
Soundproof treament
|
steel sheet, sound dampening mat, acoustic panel etc.
|
|
|
Base board
|
15 mm /18mm plywood /MDF/HDF/HPL
|
|
|
Surface finish
|
Bare board, plywood, melamine, fabric, PU, HPL, wood ect./customized
|
|
|
STC
|
45db - 56db
|
|
|
Weight
|
38-60kg/㎡
|
|
|
Fire retartdant
|
Optional
|
|
|
Applicable Height
|
5m to 20m
|
|
|
Passing door
|
Single/double leaf
|
|
|
Panel Configuration:
Coating THK: um Wesbster Hardness:
hw
|
1.Outer Frame:6061-12um-15hw
2.Inner Frame: 3.0mm hot dip galvanizing C-shape steel+1.2mm hot dip galvanizing square steel tube 3.Rockwool：100kg/m³ 4.Board THK：15mm |
|
