Quick Details
-
Brand Name:
-
YISHAN
-
Model Number:
-
TS160H
-
Dimension(Long * Breadth * High):
-
5779*4150*3079mm
-
Product name:
-
crawler dozer
-
Model:
-
TS160H
-
Brand:
-
YISHAN
-
Engine Model:
-
Weichai WP10G178E355
-
Operation weight:
-
17678 kg
-
Rated Power:
-
131/1850 KW/rpm
-
Max torque:
-
830/1150 N.m/rpm
-
Grade ability:
-
30°
-
Blade capacity:
-
4.0m³
-
Overall dimensions of machine:
-
5779*4150*3079mm
Quick Details
-
Machine Weight:
-
17678 KG
-
Dozing Capacity:
-
4m³
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
YISHAN
-
Model Number:
-
TS160H
-
Dimension(Long * Breadth * High):
-
5779*4150*3079mm
-
Product name:
-
crawler dozer
-
Model:
-
TS160H
-
Brand:
-
YISHAN
-
Engine Model:
-
Weichai WP10G178E355
-
Operation weight:
-
17678 kg
-
Rated Power:
-
131/1850 KW/rpm
-
Max torque:
-
830/1150 N.m/rpm
-
Grade ability:
-
30°
-
Blade capacity:
-
4.0m³
-
Overall dimensions of machine:
-
5779*4150*3079mm
Product Description
|
Product Name
|
Bulldozers
|
Ground contact length
|
3140 mm
|
|
Model No.
|
TS160H
|
Shoe width
|
1070 mm
|
|
Engine
|
WP10G178E355
|
Ground Pressure
|
26.3 kpa
|
|
Rated Power
|
131/1850 kw/rpm
|
Min.ground Clearance
|
510 mm
|
|
Fuel Consumption
|
≤215 g/kw.h
|
Overall dimensions L*W*H
|
5779×4150×3079 mm
|
|
Max torque
|
830/1150 N.M/rpm
|
Blade dimension W*H
|
4150×970 mm
|
|
Blade type
|
Straight tilting type
|
Blade digging angle
|
55 °
|
|
Operation Weight
|
17678 kg
|
Blade max.ground Clearance
|
1026 mm
|
|
Min.ground radium
|
4.3 m
|
Blade max.digging Clearance
|
469 mm
|
|
Grade ability
|
30°
|
Blade max.tilt adjustment
|
789 mm
|
|
Forward （km/h
）
|
2.7/3.7/5.4/7.6/11.0
|
Number of shoes(each side)
|
44
|
|
Reverse （km/h）
|
3.5/4.9/7.0/9.8
|
System pressure
|
13.7 Mpa
|
Advantages:
1.Weichai engine has sufficient power and high combustion efficiency.
2.Electrically controlled high pressure common rail technology, low fuel consumption.
3.With 8 support wheels, 5 unilateral and 3 bilateral, the track section is increased to 46.
4.JC160D mechanical drive wetland bulldozer,with high adhesion performance,suitable for high water content, soft, viscous geological conditions.
