Quick Details
-
Ink Type:
-
Eco Solvent Ink
-
Place of Origin:
-
China
-
Brand Name:
-
MarC
-
Voltage:
-
110V/220V
-
Dimensions(L*W*H):
-
4690 * 1010 * 1380 mm
-
Weight:
-
700KG
-
Certification:
-
CE
-
Product name:
-
Eco Solvent Printer
-
style:
-
luxury
-
Application:
-
Indoor Outdoor Advertisement
-
Printhead:
-
DX7
-
Print speed:
-
4pass (20sqm/h)
-
RIP Software:
-
Photoprint
-
Media Type:
-
Adhensive Vinyl
-
Printing size:
-
1800mm
-
Resolution:
-
1440 DPI
Quick Details
-
Print Dimension:
-
1.6m-3.2m
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Ink Type:
-
Eco Solvent Ink
-
Place of Origin:
-
China
-
Brand Name:
-
MarC
-
Voltage:
-
110V/220V
-
Dimensions(L*W*H):
-
4690 * 1010 * 1380 mm
-
Weight:
-
700KG
-
Certification:
-
CE
-
Product name:
-
Eco Solvent Printer
-
style:
-
luxury
-
Application:
-
Indoor Outdoor Advertisement
-
Printhead:
-
DX7
-
Print speed:
-
4pass (20sqm/h)
-
RIP Software:
-
Photoprint
-
Media Type:
-
Adhensive Vinyl
-
Printing size:
-
1800mm
-
Resolution:
-
1440 DPI
1. Exported to more than 150 countries overseas through strict standards in Europe and America; including photo machine, inkjet printer, heat transfer machine, UV roll-to-roll machine, laser machine, engraving machine, fiber optic machine, marking machine, UV plate, Ink, materials, etc.
2.One year quality guaranty, the machine with main parts(excluding the consumables)
shall be changed free of charge when if any problem during the warranty period.
3.Lifetime maintenance free of charge.
4.Free training course at our plant.
5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery
|
MC3202B5 |
||
|
Print Head |
With double DX5 high speed industrial print head, 180 nozzles*8 Lines*1, high quality up to 1440dpi |
|
|
Maximum Print Width |
3200mm |
|
|
Print Resolution / Speed |
Produce Mode:4 5 square meter/H |
|
|
Resolution Mode:30 square meter/H |
||
|
High Resolution Mode:2 5 square meter/H |
||
|
Ink |
Sort |
Eco solvent/water based inks |
|
Capacity |
1.5L Empty Ink Supply System |
|
|
Media |
Width |
3300mm |
|
Thickness |
1.5mm to 8mm adjustable |
|
|
Maximum Roll Weight |
225KG |
|
|
Sort |
PP Sythentic Paper,Backlit, Photographic Paper, Sublimation paper, Banner, Flag and so on. |
|
|
High Printing Quality |
VSD technology |
|
|
Media Heater |
Pre /Back Heater ( Optional ) |
|
|
Media Take-up Device: Double motor automatic media take-up device |
||
|
Drying System: Fan& Infrared ray drying system |
||
|
Thickened and thick THK guide rail made in Japan |
||
| New Beijing system | ||
|
lifting ink stack, automatic anti-collision system |
||
|
lifting ink stack, automatic anti-collision system |
||
|
JMC integrated motor
|
||
|
Sheet metal heavy drawing, stable, heavy fan
|
||
|
Interface |
( 1000Mbit/s ) |
|
|
RIP Software |
Maintop V5.3, Maintop V6.0,Photo print, Wasatch |
|
|
Voltage |
AC 110V ± 10 % , AC 220 V ± 10 % , 50 / 60 ± 1Hz |
|
|
Operation Environments |
Temperature: 15℃-30℃, Humidity: 35%RH-65%RH |
|
|
Power |
5000W |
|
|
Dimensions of Printer(L*W*H) |
4690 * 1010 * 1380 mm |
|
|
Dimensions of Packing(L*W*H) |
4800 * 1135 * 1480mm |
|
|
Net Weight |
700KG |
|
|
Weight |
900KG |
|
FAQ & FRIENDLY REMINDER
1. What kind of material can print?
Vinyl, coating paper, photo paper, PVC ,polyester, flex banner, Canvas,Eco solvent material etc. If the material you want to print is not in the above range, please contact our sales engineer
2. Printing width?
1.6m / 1.8m / 3.2m
3. Printing speed ?
Can reach 21sqm/hour for the printer with only one Epson DX5 head,42sqm/hour for the printer with two Epson DX5 heads
4. After-sale services and maintainance?
Our warranty time is 12 month, during warranty time, send broken part back, we send you new.
Video for installation of printhead and maintainance.
24hours on line tech support, install software for you by online service
5. Shipment ?
Packing in strong wooden case
Packing size:
2.9m*0.75m*0.65m /200kgs for the 1.6m
3.0m*0.75m*0.65m /250kgs for the 1.8m
4.53m*1.16m*1.58m /500kgs for the 3.2m
6. Delivery time:
Within 3 days after receive the deposit
7. Standard equipment with machine
Software driver CD, operation manual CD, power line, spare parts, ink adding and cleaning tool, assemble tools
