Quick Details
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
JOYMANDE
-
Dimension(L*W*H):
-
5500x1300x1800mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support
-
Processing:
-
Washer
-
Processing Types:
-
plastic box/fruit/vegetable
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
None
-
Showroom Location:
-
None
-
Certification:
-
CE
Quick Details
-
Cleaning Process:
-
Alkaline Cleaning
-
Power:
-
25-65kw
-
Max. Pressure:
-
0.4MPA
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
JOYMANDE
-
Dimension(L*W*H):
-
5500x1300x1800mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support
-
Processing:
-
Washer
-
Processing Types:
-
plastic box/fruit/vegetable
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
None
-
Showroom Location:
-
None
-
Certification:
-
CE
We could offer the crate tray wash ing machine d epending on your requirements.
The price differs according to the crate size,washing capacity and application of the crates..
Our tray washer could handle most of the vast variety of sizes, shapes of plastic crate /boxes/trays/basket/plastic pallet/ plastic cage/barrel etc.
Our tray washer is with capacities from 50-1200 crates/ hour depending on the degree of soilage.
The crate washer machine consist of 3 separate washing systems:
- H ot alkaline water cleaning or hot water cleaning(0-90 ° C adjustable)
- Hot water cleaning or cold water cleaning (0-90 ° C adjustable)
- Cold water rinsing part
Each part is configured with separate water tank, water pump and double filter trays to prevent any blockage. The water could be re-circulated using with low water consumption.
The entire machine (incl. pipes, nozzles) is built up in AISI 304
Options:
- Pre-rinse section
- Heating mode: Steam, hot water, gas and electric
- Overhead conveyor for “ one man ” operation
- Disinfection
- Automatic destacking, drying and stacking
Unique characteristics:
- Manual variable top and side guides for handling of multiple crate sizes
- Suitable for various industry and plastic boxes/crates/trays/baskets/bins etc
- Plug and play solution
- Easy to operate and maintain
- 24x360 days working time available
- Long service time
- Environmental friendly-low water and detergent consumption
- Cross nozzles to ensure that all surfaces are cleaned
- Stainless steel nozzles
- Double filter to prevent any blockage in the pump or nozzles
Application:
Supermarket
Food industry
Bakery
Confectionary
Dairy
Fish
Fruit and vegetable
Meat
Pharmaceutical
Poultry
Retail / Pooling systems
Automotive
|
JME400 |
1 st water pump |
2 nd water pump |
Heating power |
Conveyor power |
Speed reduction box power |
Output PCS/h |
Size mm |
||
|
4KW |
4KW |
27kw |
1.5KW |
0.75kw |
100-600 |
4000x1300x1700 |
|||
|
JME550 |
1 st water pump |
2 nd water pump |
3 rd water pump |
Heating power |
Conveyor power |
Speed reduction box power |
Output PCS/h |
Size mm |
|
|
4KW |
4KW |
2.2KW |
27kw |
1.5KW |
0.75kw |
100-600 |
5500x1400x1800 |
||
|
JME800
|
1 st water pump |
2 nd water pump |
3 rd water pump |
4 th water pump |
Heating power |
Conveyor power |
Speed reduction box power |
Output PCS/h |
Size mm |
|
5.5KW |
5.5KW |
2.2KW |
2,2kw |
27kw |
1.5KW |
0.75kw |
200-800 |
8000x1450x1800 |
|
|
JME 11 00
|
1 st water pump |
2 nd water pump |
3 rd water pump |
4 th water pump |
Heating power |
Conveyor power |
Speed reduction box power |
Output PCS/h |
Size mm |
|
5.5KW |
5.5KW |
4 KW |
2,2kw |
27kw |
1.5KW |
0.75kw |
200- 1200 |
11 000x1450x1800 |
|
Drying Machine Available:
|
Drying machine |
Conveyor power |
Speed reduction box power |
Vortex blower power |
Centrifugal blower power |
|
JME400 |
1.5KW |
1.5kw |
11kw |
0.75kw*6pcs |
|
JME600 |
1.5KW |
1.5kw |
11kw |
0.75*12pcs |
|
JME750 |
1.5KW |
1.5kw |
22kw |
0.75*24pcs |
