Quick Details
-
Warranty:
-
1years
-
Brand Name:
-
JSG DC PUMP
-
Model Number:
-
BD-07A/BD-07V
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
N/M
-
Cable Length:
-
{-8-N/M}
-
Outlet Size:
-
OD:8.3mm,ID:4.5mm
-
Power:
-
24-50W
-
Item:
-
Electric Micro Pump
-
Other name:
-
Mini Dc Fountains Pump,Nebulizer Mini Air Pump
-
Motor:
-
dc brush motor(can choose brushless motor)
-
Pump head material:
-
PPS
-
diaphragm material:
-
EPDM(can choose corrosion resistant)
-
Medium:
-
air/gas
-
Working time:
-
Continuous or intermittent
-
Feature:
-
Oilless, High pressure, High flow
-
Theory:
-
Reciprocating Pump
-
MOQ:
-
1 PCS
Quick Details
-
Application:
-
Other, Automotive Industry, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, Industrial Utilities, Irrigation and Agriculture, Machining, Metal and Equipment Manufacturers, Pharmaceutical industry, Washing and Cleaning, Water Distribution, Water Treatment Solutions, Other
-
Pressure:
-
High Pressure
-
Voltage:
-
12V/24V
-
Warranty:
-
1years
-
Brand Name:
-
JSG DC PUMP
-
Model Number:
-
BD-07A/BD-07V
-
Place of Origin:
-
Guangdong, China
-
Horsepower:
-
N/M
-
Cable Length:
-
{-8-N/M}
-
Outlet Size:
-
OD:8.3mm,ID:4.5mm
-
Power:
-
24-50W
-
Item:
-
Electric Micro Pump
-
Other name:
-
Mini Dc Fountains Pump,Nebulizer Mini Air Pump
-
Motor:
-
dc brush motor(can choose brushless motor)
-
Pump head material:
-
PPS
-
diaphragm material:
-
EPDM(can choose corrosion resistant)
-
Medium:
-
air/gas
-
Working time:
-
Continuous or intermittent
-
Feature:
-
Oilless, High pressure, High flow
-
Theory:
-
Reciprocating Pump
-
MOQ:
-
1 PCS
Use for Air/Vacuum Pump Parameter
| Name | Model | Voltage |
No-load
Current |
Max
Pressure |
Max Vacuum | Max Flow | Noise |
| Air pump | BD-07A | 12V | ≤2A | ≥450kpa | / | ≥17L/min | low |
| ≤2.5A | ≥500kpa | / | ≥25L/min | ||||
| ≤4A | ≥600kpa | / | ≥35L/min | ||||
| Vacuum pump | BD-07V | ≤2A | / | ≥-85kpa | ≥17L/min | ||
| ≤2.5A | / | ≥-85kpa | ≥25L/min | ||||
| ≤4A | / | ≥-86kpa | ≥35L/min |
Remark:
1. "A"means air pump, "V"means vacuum pump
2. Dear customer, for custom parameters , please refer to the third table
3. Pressure unit conversion:
10kpa=0.01Mpa=0.1bar=100mbar=1.45psi=75mmHg=1019.7kgf/m2
100kpa=0.1Mpa=1bar=1000mbar=14.5psi=750mmHg=10197kgf/m2
General Specification
| Dimention | 108x87x43mm |
| Inlet/Outlet | ID:8.3mm/OD:4.5mm |
| Weight | 580g |
| Materials | Pump head PPS, membrane EPDM, valve EPDM |
| Working Mode | Interrupt |
| Motor | Brush DC Motor |
| Life time | 1000H |
| Environment Temperature range | 0-40℃ |
| Ambient humidity range | <80% RH |
Dimention
Product Details
Typical Appliaction
More Appliaction
1.Portable cow and sheep milker
2.Medical electric aspirator
3.Vacuum packaging machine
4.Medical sputum aspirator
5.Beauty industry
6.Portable devices
7.Small equipment
8.Physiotherapy
9.Balloon pump
10.Gas analysis
11.Ventilator
12.Tire pump
13.Mounter
....
Custom Parameters
| Motor | Brush DC Motor | Brushless DC Motor |
| Lifetime | 1000H | 3000H |
| Voltage | 12V/24V | |
| Positive Pressure range | 450-650kpa | |
| Negative Pressure range | 80-87kpa | |
| Air flow range | 15-40L/min | |
| Working Mode | Continuous or intermittent | |
1.Pressure unit conversion:
10kpa=0.01Mpa=0.1bar=100mbar=1.45psi=75mmHg=1019.7kgf/m2
100kpa=0.1Mpa=1bar=1000mbar=14.5psi=750mmHg=10197kgf/m2
2.If you are interested in our products, please
contact us
Brush motor
| Lead angle | Two(+,-) |
Brushless motor
| 2 Wire | Red(+),Black(-) |
| 3 Wire | Red(+),Black(-),Green(PWM) |
| 4 Wire | Red(+),Black(-),Green(PWM),Yellow(tachometere) |
