Quick Details
-
Brand Name:
-
Leizhan
-
Voltage:
-
/
-
Power:
-
/
-
Dimension(L*W*H):
-
/
-
Weight:
-
1200 kg
-
Product name:
-
Kraft paper machine
-
Raw material:
-
Waste carton box,wood pulp
-
Output paper:
-
Kraft paper
-
Basis weight:
-
80-220g/m2
-
Trimmed width(mm):
-
1880-5800
-
Operating speed(m/min):
-
150-800
-
Function:
-
Paper recycling machine
-
Application:
-
Paper making Industry
-
After Warranty Service:
-
Video technical support
-
Keyword:
-
Paper recycling machine for paper mill
Quick Details
-
Production Capacity:
-
Other
-
Product Type:
-
corrugated paper making machine
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Leizhan
-
Voltage:
-
/
-
Power:
-
/
-
Dimension(L*W*H):
-
/
-
Weight:
-
1200 kg
-
Product name:
-
Kraft paper machine
-
Raw material:
-
Waste carton box,wood pulp
-
Output paper:
-
Kraft paper
-
Basis weight:
-
80-220g/m2
-
Trimmed width(mm):
-
1880-5800
-
Operating speed(m/min):
-
150-800
-
Function:
-
Paper recycling machine
-
Application:
-
Paper making Industry
-
After Warranty Service:
-
Video technical support
-
Keyword:
-
Paper recycling machine for paper mill
Waste Paper Recycling Machine Corrugated Cardboard Kraft Paper Machine in Paper Making Industry
Paper making machine introduction
The paper machine mainly use waste paper as raw material, then produce kraft paper, carton paper, etc. We can supply full line of pulp and paper making.
Paper making machine raw material
Paper making machine specification
|
Kind of paper |
high quality kraft paper.carton paper,etc
|
|
Basis weight |
60-220g/m2 |
|
Trimmed width |
1880-5800mm |
|
Working speed |
100-800m/min |
|
Production |
30-750 t/d |
|
Drive |
frequeny control of motor speed sectional drive |
Paper making machine details
Paper machine is divided into the following parts: headbox, long wire, press section, front dryer section, skewed surface sizing machine, back dryer section, coiling.
1.Headbox:Air-cushioned headbox, by controlling the headbox gas pressure to control and stabilize the sizing pressure head of wire pulp.
2.Wire section:Single long wire, the main components: chest roll, forming plate, dehydration board, vacuum box, vacuum underlying rollers, drive roll, guide roller and rack.
3. Press section
Divided into a press, two press, three press. A K-type composite press with a vacuum suction roller, K-type composite press is equipped with a coated metal roller, a vacuum press roll, a stone roller, and with the next felt; two press, three press for the big roll diameter press, each with two coated metal roller, and with, under the felt. A press, two presses, three presses are equipped with a felt roller and felt section box. A press, two press, three press pressing method for the corrugated gas tire pressure
4.Drying part front dryer section 24 Φ1800 dryer cylinder, 8 +8 +8group drive, with semi-enclosed hood; Back dryer section is 12Φ1800 dryer, 6+6 group drive, with semi-enclosed hood.
5.S kewed surface sizing machine: the surface of a chrome-plated metal roll, one package of metal roller. The surface of the press is pressurized by corrugated gas.
6.C oiling: Pneumatic Horizontal Rollers
Our service
Pre-sales service:
1.Offering comprehensive technical and business consultation services.
2.Proposing the most suitable scheme and equipment for our clients.
3.Designing and fabricating targeted products according to the special requirements of clients.
4.Training periodically high qualified service technician.
After-sales service:
1.Assisting our clients for foundation construction of equipment.
2.Dispatching engineers to install and debug equipment.
3.Training the first-line operators on site.
4.Regularly visit clients to solve production problem.
Corrugated cardboard making machine packaging and delivery
2. Container (as customer requirements)
3. It is suitable for long distance ocean transportation.
FAQ
A: We can offer the whole pulp and paper production line. From factory design to machine installation and training, our company can supply for you all.
Are your a manufacturer?
A: Yes. Of course we are. We are spealized in pulp & paper equipment manufacturing in China for 42 years. There are about 50 paper mills near our factory and most of them are using our machines. So, welcome to visit our factory and I believe you will be satisfied with our products.
What's your advantages?
A: We have 42 years experience in the field of paper making industry. 20000 square meters workshop with more than 200 staffs including 50 engineers. ISO9001:2000 and BV certification. Strict quality control of every procedure.
