Quick Details
-
Precision:
-
High Precision High Performance
-
Color:
-
Red
-
Motor:
-
0.75KW
-
Taper of tailstock sleeve:
-
MT2
-
Height of center:
-
125mm
-
Spindle speed:
-
400-1640rpm
-
Spindle Taper:
-
MT3
-
Max.Swing Over Bed:
-
250mm
-
Max.Length Cutting:
-
420(660)mm
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KY
-
Weight (KG):
-
200
-
Precision:
-
High Precision High Performance
-
Color:
-
Red
-
Motor:
-
0.75KW
-
Taper of tailstock sleeve:
-
MT2
-
Height of center:
-
125mm
-
Spindle speed:
-
400-1640rpm
-
Spindle Taper:
-
MT3
-
Max.Swing Over Bed:
-
250mm
-
Max.Length Cutting:
-
420(660)mm
Product Description
|
Specification
|
|
|
|
Model No.
|
KY450/KY700
|
|
|
Height of center
|
125mm
|
|
|
Max.distance between two centers
|
450(700)mm
|
|
|
Max.length cutting
|
420(660)mm
|
|
|
Max.swing over bed
|
250mm
|
|
|
Max.swing over carriage
|
130mm
|
|
|
Taper of spindle nose
|
MT4/27mm
|
|
|
Spindle speed range
|
115-1620rpm
|
|
|
Matric thread cutting
|
0.2-3.5mm(20 kinds)
|
|
|
Inch thread cutting
|
8-56/1(20 kinds)
|
|
|
Moulder thread cutting
|
0.1-1.25mm(10kinds)
|
|
|
Range of longitudinal feed
|
0.05-0.1mm
|
|
|
Max.round angle of tool post
|
45°
|
|
|
Max.travel of tool post
|
70mm
|
|
|
Taper of tailstock sleeve
|
MT2
|
|
|
Motor
|
0.75kw
|
|
|
Drilling/Milling
|
|
|
|
Spindle taper
|
MT3
|
|
|
Spindle stroke
|
80mm
|
|
|
Spindle nose to table
|
160mm
|
|
|
Milling table size
|
215*150mm
|
|
|
Spindle speed
|
400-1640rpm
|
|
|
Motor poser
|
550W
|
|
|
Standard accessories
|
|
|
|
Splash guard
|
1 pc
|
|
|
Chip tray
|
1 pc
|
|
|
Drawbar
|
1 pc
|
|
|
Arbor
|
1 pc
|
|
|
Toolbox & tools
|
1 set
|
|
|
Optional accessories
|
|
|
|
4-jaw chuck
|
1 set
|
|
|
Backplate
|
1 pc
|
|
|
Follow rest
|
1 pc
|
|
|
Steady rest
|
1 pc
|
|
|
Face plate
|
1 pc
|
|
|
Collet chuck
|
1 set
|
|
|
Turning tools
|
1 pc
|
|
