Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HM
-
Model Number:
-
HM-KS1605
-
stroke:
-
2.00mm
-
elecctrical life:
-
2000cycles
-
contact resistance:
-
50MΩ max at initial 100MΩ max after life test
-
Dielectric strength:
-
500VDC/1MIN
-
materials:
-
plastics,alloy copper gold plating
-
capacitance:
-
5PFMAX
-
insulation resistance:
-
100MΩ ,500VDC
-
Non-swtiching rating/ switching rating:
-
100MA.50VDC/25MA 24VDC
-
operating temp/storage temp:
-
-20°C-70°C/-40°Cto 85°C
-
Certification:
-
ROHS
Quick Details
-
Protection Level:
-
1
-
Max. Current:
-
1A
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HM
-
Model Number:
-
HM-KS1605
-
stroke:
-
2.00mm
-
elecctrical life:
-
2000cycles
-
contact resistance:
-
50MΩ max at initial 100MΩ max after life test
-
Dielectric strength:
-
500VDC/1MIN
-
materials:
-
plastics,alloy copper gold plating
-
capacitance:
-
5PFMAX
-
insulation resistance:
-
100MΩ ,500VDC
-
Non-swtiching rating/ switching rating:
-
100MA.50VDC/25MA 24VDC
-
operating temp/storage temp:
-
-20°C-70°C/-40°Cto 85°C
-
Certification:
-
ROHS
Thermostat electric temperature furnace 5 key switch
Thermostat electric temperature furnace 5 key switch
|
Electrical Rating |
1A250V AC, 4A250V AC |
|
Button distance |
13.5mm 16mm 18mm 21mm .... |
| Temp(C) | -25°C to 85°C |
| Circuit/ Functions | OFF L1 L2 L3 L4 |
| Wiring specifications | 22-18AWG UL1015 |
| The keyboard distance | 13.5mm 16mm, 18mm 21mm |
| Wire Connect |
Soldering wires or Inserting wires (without terminals outside) |
| life time |
10000cycles |
| Housing: PC /PBT/PA66 | |
| Cover: PC /PBT/PA66 | |
| Push block: PA66 | |
| Actuating Tip: Copper Button: Stainless steel or iron | |
| Locking Plate: Zinc Plating Iron Blocking Plate: steel/iron | |
| Terminal Spring: stainless steel Stationary terminal: Copper alloy | |
| Spring: Steel |
Q1: Are you a factory or trader?
we are a factory.
Q2: Why choose your company?
1.more than ten years manufacture experience about more kinds of switch
2.good quality,competitive price,fast delivery time
3.more switch type choosed,such as keyboard switch,rotary switch,rocker switch, push button switch, slide switch,dip switch,micro switch,tact switch,ac/dc socket and connector.
4.Design and Develop new mould depends on clients requirement
5.The best after-sale service
6.Anytime you need help ,please contact with us we keep online all the time.
Q3: How to get the samples and quote the best price soon?
we need to know more details about the products you inquired,for example
what functions?what size?what rating?where the type to be used?
we free to offer the samples
Q4.How about the delivery time?
Gernally speaking it is need 2 weeks if your quantity below 10K pcs or it depends on your quantity to confirm the time.
Q5:How about the package of the goods?
we often package the goods more safty, both inner box and outside cartons
more related product details,please feel free to contact with us!
