Quick Details
-
Warranty:
-
1.5 years
-
Engine Brand:
-
quanchai
-
Product name:
-
FL404 Tractor
-
Engine:
-
Quanchai
-
Engine type:
-
4 Cylinder Diesel engine
-
brand:
-
horsen
-
Dimension(L*W*H):
-
3970*1620*2130
-
Clutch:
-
Double Stage Clutch
-
Transmission:
-
12F+12R Shifts
-
front loader price:
-
2450 USD
-
slasher mower price:
-
780 USD
-
tractor price:
-
contact Horsen international
Quick Details
-
Rated Power (HP):
-
40 HP
-
Brand Name:
-
Horsen
-
Place of Origin:
-
Shandong, China
-
Warranty:
-
1.5 years
-
Engine Brand:
-
quanchai
-
Product name:
-
FL404 Tractor
-
Engine:
-
Quanchai
-
Engine type:
-
4 Cylinder Diesel engine
-
brand:
-
horsen
-
Dimension(L*W*H):
-
3970*1620*2130
-
Clutch:
-
Double Stage Clutch
-
Transmission:
-
12F+12R Shifts
-
front loader price:
-
2450 USD
-
slasher mower price:
-
780 USD
-
tractor price:
-
contact Horsen international
FL404 series
HOT SALE technical features:
- Direct injection engine, optional domestic 4-cyl diesel engine, which can meet different operation requirements.
- transmission structure with 8F +4R, 8F+8R, 12F+12R
- Gear box, rear axle with matured technology and steady quality.
- New streamlined hood, nice appearance.
- Hydraulic steering, small steering radius, portable and flexible.
- Optional dry or wet air filter, internal or external muffler.
- for more, contact HORSEN
| Main parameters | ||
| Type | FL404 | |
| Drive type |
four-wheel drive |
|
| Engine | ||
| Engine Brand | ||
| Engine Type | QC490T40 | |
|
Max. Torque (Nm @ engine rpm) |
170~175/1700 | |
| Fuel tank capacity (L) |
38L+22L=60L
48L+22L=70L |
|
|
Rating power of engine KW/RPM |
29.4/2400 | |
|
Fuel consumption @ nominal power (g/kw.h) |
≤248 | |
| Air Intake Type | Natually-Aspirated | |
| Displacement L | 4/2.977 | |
| Air filter type/size | ||
| Torque reserve | 18% | |
| Transmission system | ||
| Clutch type/size |
One-piece,dry,double-action/10 inches |
|
| No. of gears (F+R) | 8F+4R/8F+8R/12F+12R | |
| Shift method |
mechanical sliding sleeve |
|
| Max. speed | 34.78 | |
| Gear position | side position | |
| Hydraulic system | ||
|
Hydraulic output flow rate (L / MIN) |
38.4 | |
|
Hydraulic output valve |
One group/Two groups/Three groups/Simple hydraulic output |
|
|
Hydraulic filter types and capacity |
wire mesh/63μm | |
| Working device | ||
| Three-point-linkage |
1 Type/2 Type (Optional) |
|
| PTO Speed |
540/760rpm
540/1000rpm(Optional) |
|
| Lifting Capacity kn |
9KN/15KN(Enforced lift) |
|
| Tillage depth adjustment |
Draft, position,position and draft mix control/position,float(Enforced lift) |
|
| Parameter | ||
|
The whole machine size (dimensions) mm |
3790×1520×2130
3790×1620×2130 |
|
|
(kg)
Min. operation mass |
With cab | 2300 |
| Without cab | 2120 | |
| Wheel base (mm) | 1992 | |
| Mini turning Radius (m) | 3.8 | |
| Rated traction force(N) | 11 | |
| Deck | Flat Deck | |
| Minimum ground clearance (mm) | 325 | |
| Heat ventilation cab | Optional | |
| Front/rear wheel tread |
1200/1200
1250/1300 (common 1300) |
|
| tyre size | 8.3-20/12.4-28 | |
| Braking and steering | ||
| Braking system |
Wet type,disc brake |
|
| Steering type |
hydraulic steering |
|
| Steering Angle (4 x4) |
|
|
|
(options: all these types can Optional for ROPS ,Sunshade,swing drawbar, front/rear ballast,cabin) |
||
