- Product Details
- {{item.text}}
Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12270
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Video technical support, Online support, Free spare parts
-
Place of Origin:
-
Hubei, China, China
-
Dimensions (L x W x H) (mm):
-
10245x2496x3386 mm
-
Cargo Tank Dimension:
-
8545*2496*3350 mm
-
Product name:
-
Tipper Dump Truck
-
Brand:
-
IVECO/SIONTRUK/Isuzu/Dongfeng/Faw/Fonton/JAC
-
Keywords:
-
Dump Truck Dumper Truck Tipper Truck
-
Driving type:
-
LHD RHD
-
Color:
-
Customer's Request
-
Transmission:
-
10 Forwards
-
Type:
-
Dumping Truck
-
Name:
-
Tipper Truck
-
Drive:
-
4X2 Wheel
Quick Details
-
Condition:
-
New
-
Horsepower:
-
351 - 450hp
-
Emission Standard:
-
Euro 3
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12270
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Video technical support, Online support, Free spare parts
-
Place of Origin:
-
Hubei, China, China
-
Dimensions (L x W x H) (mm):
-
10245x2496x3386 mm
-
Cargo Tank Dimension:
-
8545*2496*3350 mm
-
Product name:
-
Tipper Dump Truck
-
Brand:
-
IVECO/SIONTRUK/Isuzu/Dongfeng/Faw/Fonton/JAC
-
Keywords:
-
Dump Truck Dumper Truck Tipper Truck
-
Driving type:
-
LHD RHD
-
Color:
-
Customer's Request
-
Transmission:
-
10 Forwards
-
Type:
-
Dumping Truck
-
Name:
-
Tipper Truck
-
Drive:
-
4X2 Wheel
Product Description
Japan Isuzu 5 ton automatic tipper dump truck 4x2 tipper mini trucks for sale in USA
The detail image of the tipper dump trucks
Specification
The Detailed parameters of dump truck
| Chassis brand | IVECO Kingkan | Drive type | 8x4 |
|
Product name
|
Dump truck | Total mass | 18000kg |
| Curb weight | 14970kg |
Overall dimension
|
8070x2500x3460mm
|
| Load weight | 50000kg |
Box
dimension
|
6000x2300x1100mm
|
| Wheel base | 1800+3625+1350mm |
F/R axle load
|
6500,6500/18000kg
(Tandem)
|
|
Quantity of leaf spring
|
8/8/12 |
Quantity of tires
|
12+1
|
| Tyre type | 11.00R20 18PR | Approach/ |
25/20°
|
| Departure angle | |||
| F/R suspension | 1435/1860mm | Front track |
2006,2006mm
|
| Rear track | 1850,1850mm |
Max.vehicle speed
|
80km/h
|
| Passengers in cab | 2 |
Chassis model
|
CQ3315
|
| Engine | Model |
WP10.300E40
|
|
| Max.power |
221kw/300HP
|
||
| Displacement |
9726ml
|
||
| Emission level |
Euro 4
|
||
| Description |
In line ,6 cylinders,4 strokes,water cooled,inter cooled,turbo
|
||
|
charged,diesel engine
|
|||
| Gearbox |
Description
|
Manual,10 forward gears&1 reverse gear
|
|
| Brake | Service brake |
Double circuit pneumatic (air) brake
|
|
| system | Parking brake |
Spring-power drum brake
|
|
| Electric system | Operating voltage |
24V negative grounded
|
|
| Starter |
24V,5.4KW
|
||
| Alternator |
28V,1.5KW
|
||
| Battery voltage |
2X12V/165Ah
|
||
| Cabin | Description |
One and half rows,single sleeper,luxury sedan
|
|
|
configuration,power steering,A/C
|
|||
