Quick Details
-
Reverse Speed(km/h):
-
25
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Oriemac
-
Weight:
-
5000 kg
-
Dimension(L*W*H):
-
6880*2375*3150mm
-
Tractive force(f=0.75):
-
41.6KN
-
Tire inflation pressure:
-
350KPa
-
Maximum lift above ground:
-
300mm
-
Max. gradeability:
-
20%
-
Transmission pressure:
-
1.3~1.8MPa
-
Maximum depth of cutting:
-
350mm
-
Rated power/speed:
-
75/2400kw/rpm
Quick Details
-
Forward Speed(km/h):
-
39
-
Engine Brand:
-
J-XZGR100-4BT3.9
-
Working diameter:
-
Contact supplier
-
Reverse Speed(km/h):
-
25
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Oriemac
-
Weight:
-
5000 kg
-
Dimension(L*W*H):
-
6880*2375*3150mm
-
Tractive force(f=0.75):
-
41.6KN
-
Tire inflation pressure:
-
350KPa
-
Maximum lift above ground:
-
300mm
-
Max. gradeability:
-
20%
-
Transmission pressure:
-
1.3~1.8MPa
-
Maximum depth of cutting:
-
350mm
-
Rated power/speed:
-
75/2400kw/rpm
GR100 100HP Mini Motor grader With Blade/Ripper For Sale
Product Description
1.GR100 adopts Dongfeng Cum--mins 4BTA3.9-C100-II (SO11847) turbocharged diesel engine with large output torque and power reserve
coefficient and low fuel consumption.
2.The torque converter has a large torque coefficient, a high efficiency, a wide effective area, and a good joint operation
characteristic with the engine.
3.The drive axle is a dedicated axle.
4.Rear axle main drive is equipped with "NO-SPIN" without self-locking differential. When one wheel slips, the other wheel can
still transmit its original torque.
5.The service brake is a dual-circuit hydraulic brake system that acts on the two rear wheels of the grader and is safe and
reliable.
6.The sealed cab is used to configure the air conditioning system. The interior parts are sleek and compact plastic parts, which
fully reflects the needs of ergonomics.
coefficient and low fuel consumption.
2.The torque converter has a large torque coefficient, a high efficiency, a wide effective area, and a good joint operation
characteristic with the engine.
3.The drive axle is a dedicated axle.
4.Rear axle main drive is equipped with "NO-SPIN" without self-locking differential. When one wheel slips, the other wheel can
still transmit its original torque.
5.The service brake is a dual-circuit hydraulic brake system that acts on the two rear wheels of the grader and is safe and
reliable.
6.The sealed cab is used to configure the air conditioning system. The interior parts are sleek and compact plastic parts, which
fully reflects the needs of ergonomics.
Specification
|
Basic specification
|
|
|
|
Engine model
|
4BT3.9
|
|
|
Rated power/speed
|
75/2400kw/rpm
|
|
|
Dimension(LxWxH)
|
6880×2375×3150mm
|
|
|
Operating weight(Standard)
|
7000kg
|
|
|
Performance specification
|
|
|
|
Travelling speed ,forward
|
5,10,20,39km/h
|
|
|
Travelling speed ,reverse
|
8,25km/h
|
|
|
Tractive force(f=0.75)
|
41.6KN
|
|
|
Max. gradeability
|
20%
|
|
|
Tire inflation pressure
|
350KPa
|
|
|
Working hydraulic pressure
|
16MPa
|
|
|
Transmission pressure
|
1.3~1.8MPa
|
|
|
Operating specification
|
|
|
|
Max. steering angle of front wheels
|
±50°
|
|
|
Max. lean angle of front wheels
|
17°
|
|
|
Max. oscillation angle of front axle
|
±15°
|
|
|
Max. oscillation angle of balance box
|
|
|
|
Frame articulation angle
|
±27°
|
|
|
Min. turning radius using articulation
|
5.9m
|
|
|
Biade
|
|
|
|
Maximum lift above ground
|
300mm
|
|
|
Maximum depth of cutting
|
350mm
|
|
|
Maximum blade position angle
|
45°
|
|
|
Blade cutting angle
|
28°—70°
|
|
|
Circle reversing rotation
|
120°
|
|
|
Moldboard width X height
|
3048×500mm
|
|
Product Show
Right elevation
Left elevation
Rear elevation
