- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
XC-9610
-
Dimension:
-
213x213x165mm
-
Power Supply Mode:
-
DC24V/1A
-
SNR:
-
≥80dB
-
Output Power:
-
≤25W
-
Shell Material:
-
Mental
-
The body material:
-
Mental
-
Interface:
-
RJ45 Ethernet Port, Power Input
-
Weight:
-
1.4KG
-
S/N (Signal-to-Noise) Ratio:
-
≥80dB
-
Frequency Response:
-
100Hz-18kHz
-
Power Supply:
-
DC 24V/1A or PoE (IEEE802.3af)
-
Network Protocol:
-
SIP 2.0 (RFC 3261), FTP, HTTP, TCP/IP, UDP, ARP, ICMP, IGMP
-
Audio Codec:
-
G.711 A-law, G.711 μ-law, G.722
-
Maximum SPL:
-
97dB±3dB
-
Optional Accessories:
-
Power Adapter, IEC C13 Power Cord (US/EU/UK/AU)
-
Key Words:
-
Ceilling Speaker
Quick Details
-
Warranty:
-
2 year
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Spon
-
Model Number:
-
XC-9610
-
Dimension:
-
213x213x165mm
-
Power Supply Mode:
-
DC24V/1A
-
SNR:
-
≥80dB
-
Output Power:
-
≤25W
-
Shell Material:
-
Mental
-
The body material:
-
Mental
-
Interface:
-
RJ45 Ethernet Port, Power Input
-
Weight:
-
1.4KG
-
S/N (Signal-to-Noise) Ratio:
-
≥80dB
-
Frequency Response:
-
100Hz-18kHz
-
Power Supply:
-
DC 24V/1A or PoE (IEEE802.3af)
-
Network Protocol:
-
SIP 2.0 (RFC 3261), FTP, HTTP, TCP/IP, UDP, ARP, ICMP, IGMP
-
Audio Codec:
-
G.711 A-law, G.711 μ-law, G.722
-
Maximum SPL:
-
97dB±3dB
-
Optional Accessories:
-
Power Adapter, IEC C13 Power Cord (US/EU/UK/AU)
-
Key Words:
-
Ceilling Speaker
Product Parameters
|
Power Supply:
|
DC 24V/1A or PoE (IEEE802.3af)
|
|
|
|
|||
|
Power Consumption:
|
≤25W
|
|
|
|
|||
|
Rated Power Output:
|
20W (at DC 24V/1A powered)
15W (at PoE powered) |
|
|
|
|||
|
Network Protocol:
|
SIP 2.0 (RFC 3261), FTP, HTTP, TCP/IP, UDP, ARP, ICMP, IGMP
|
|
|
|
|||
|
Audio Codec:
|
G.711 A-law, G.711 μ-law, G.722
|
|
|
|
|||
|
Maximum SPL:
|
97dB±3dB
|
|
|
|
|||
|
S/N (Signal-to-Noise) Ratio
|
≥80dB
|
|
|
|
|||
|
Frequency Response:
|
100Hz-18kHz
|
|
|
|
|||
|
Interface:
|
1×RJ45 Ethernet Port, 1×Power Input
|
|
|
|
|||
|
IP Rating:
|
IP65
|
|
|
|
|||
|
Dimensions:
|
Φ213×165mm
|
|
|
|
|||
|
Weight:
|
1.4kg
|
|
|
|
|||
|
Standard Accessories:
|
1×2-Pin Terminal Block Connector, 1×Installation Manual
|
|
|
|
|||
|
Optional Accessories:
|
DC 24V/1A Power Adapter (US/EU/UK/AU)
|
|
|
|
|||
Connection Topology
Application
