Quick Details
-
Model:
-
HT304
-
Main dimensions (W x D x H):
-
2930X1500X2000mm
-
Wheel base:
-
1605/1730mm
-
Min. ground clearance:
-
330 mm
-
No braking:
-
2.9±0.2
-
Tractor dry mass:
-
1400 kg
-
Front/Rear Ballast:
-
50/60kg
-
Max. PTO Power:
-
19.9kw
-
Bore dia. X stroke:
-
85*95mm
-
Use:
-
Garden Home
Quick Details
-
Brand Name:
-
HIGHTOP
-
Place of Origin:
-
Shandong, China
-
Weight:
-
1400 KG
-
Model:
-
HT304
-
Main dimensions (W x D x H):
-
2930X1500X2000mm
-
Wheel base:
-
1605/1730mm
-
Min. ground clearance:
-
330 mm
-
No braking:
-
2.9±0.2
-
Tractor dry mass:
-
1400 kg
-
Front/Rear Ballast:
-
50/60kg
-
Max. PTO Power:
-
19.9kw
-
Bore dia. X stroke:
-
85*95mm
-
Use:
-
Garden Home
Parameter
|
Model |
HT304 |
|
Type |
4X4 wheeled type |
|
Main dimensions |
|
|
W XD X H (mm) |
2930X1500X2000 |
|
Wheel base (mm) |
1605/1730 |
|
Wheel tread (mm) |
|
|
Front wheel (mm) |
1070/1170/1270 Adjustable |
|
Rear wheel (mm) |
1000/1100/1200/1300 Adjustable |
|
Min. ground clearance (mm) |
330 |
|
Min. turning circle radius (m) |
|
|
When one-side braking |
2.5±0.2 |
|
No braking |
2.9±0.2 |
|
Tractor dry mass (kg) |
1400 |
|
Front/Rear Ballast (kg) |
50/60 |
|
Rated Traction (kN) |
|
|
Max. PTO Power (kw) |
19.9 |
|
Transmission box |
Mechanic gear box |
|
Gear shifts |
(4+1)X2 |
|
Theoretical speed (km/h) |
F2.07-31.54 R2.72-12.59 |
|
Differential |
closed, 2 planetary gear |
|
Differential lock |
Jaw type |
|
Diesel Engine |
|
|
Model |
3T30 |
|
Type |
Vertical 4 stroke, water cooled |
|
Number of Bores |
3 |
|
Bore dia. X stroke (mm) |
85X95 |
|
Combustion chamber |
direct injection |
|
Rated Power (kw) |
22.06 |
|
Fuel consumption (g/kw.h) |
≤248.9g/kw.h |
|
Engine oil consumption (g/kw.h) |
≤2.04g/kw.h |
|
Front tyre size |
6.00-16 |
|
Rear tyre size |
9.50-24 |
|
Steering system |
Power steering |
|
Brake |
Shoe brake |
|
Tri-point Hitch system |
Rear mounted, ball-hinged |
|
Max. lifting capacity (kN) |
4.96 |
|
PTO type |
Rear mounted, nonindependent |
|
PTO Rev. (rpm) |
540/720 r/min |
