Product Description
1. High endurance surface, longer tool life;
2. Small distortion of material;
3. Smooth molding, Fast adjustability;
4. Nice interchangeability.
5. Amada thick turret special shape form punch press tool.
Standard Thick Turret 85 Series Punch Press Tools
A/B station tool
* Spring retainer adopts two sides taper design, both sides can be used, extended punch grinding capacity.
* HQ punch body use special high-speed steel, add alloy composition, the punch body will have a longer life.
* The standard die edge thickness increase 2mm, strength increased in punching thicker plate, extend grinding capacity.
* No slug die desgn as cutting edge concave emboss, eliminate slug pulling, jumping materials and floating.
* Guide adopts lubrication design, graphite processing, to reduce the abrasion of punch turret hole.
C/D/E station punch body, die and stripper
1. The excircle of the punch body adopt lubrication design which will reduce the abrasion of the guide inner wall and increase tooling life.
2. The max. grinding capacity is 3mm, the max. shim thickness is 3mm. If need more grinding capacity, you can choose ecnomic series toolings.
3. HQ punch body use special high-speed steel, add alloy composition, the punch body will have a longer life.
4. Die inner surface adopts arc design. The punch blade has a stronger bearing strength and longer using life.
5. No slug die desgn as cutting edge concave emboss, eliminate slug pulling, jumping materials and floating.
6. Guide adopts lubrication design, graphite processing, to reduce the abrasion of punch turret hole.
C/D/E station guide assembly
1. Round and shape guide adopt integration of universal design which is convinient and cost saving than orignial design.
2. The stripper locking shrapnel with optimum design, will not hurt operator’s hand easily. And with spring steel special
processing, the elastic is better and not be broken easily.
3. The locking screw on the stripper must change after some time or else the slip teeth may cause the screw may not be removed, then the stripper will not be removed out easily. This will increase much more using cost. At the meantime, please use high quality allen wrench to disamble. This will not make the screw hole slip teeth.
4. Guide adopts lubrication design, graphite processing, to reduce the abrasion of punch turret hole.
|
Product Name
|
amada thick turret special shape form punch press tool
|
|
Material
|
SKH51 for punch; SKD11 for die
|
|
Heat Treatment
|
HRC 61°- 63°
|
|
Hits before regrinding for stainless steel
|
About 30000 hits
|
|
Hits before regrinding for mild steel
|
About 50000 hits
|
|
Tooling Life for round
|
About 800000 hits
|
|
Tooling Life for shape
|
About 600000 – 700000 hits
|
|
Delivery Time
|
3-5 working days
|
Our Service
Professional R & D Team
Tenroy has its own R & D team formed with 5 professional technicians, providing customers with mould design and selection, mould usage problem solution, mould maintenance and repair knowledge.
Quality Assurance
We adopt imported high quality tool steel. Each of our tools and blade will be tested before shipment. And their stable quality with long working life will be your best choice.
Lightning Delivery
Mass production of standard parts, smart stock! The lead time for standard type is 3-5 working days. And for special shape tools and blades, lead time is around 10-15 working days.
Packing & Delivery
Packing Details: pack with carton box, 1set/small box, many sets/big strong carton box or wooden case.
Delivery Details: 3-5 working days
1. Anti rust oil before packing
2. Suitable carton size
3. Shock bubble film
4. Professional placement
5. Professional shock
6. Complete package
Our Product Range
Full Range
A various types of tools and blades are available in our company. From punch press tools,
bending tools
to shearing blades and industrial cutters; from world famous brands of Amada, Strippit, Trumpf, Murata, Finn-Power, Nisshinbo etc. to China JFY, Yangli, Yawei, Jinan Jieda etc; from communications equipment, kitchen equipment, hotel equipment, solar energy equipment, power and electrical control cabinets, to aviation, military, ships, locomotives, cars, refrigerators, air conditioners, stoves, elevators, security door manufacturing, stainless steel decoration, cabinet manufacturing, and other sheet metal industries; we provide a full range of design and manufacturing for all the tools and blades that refer to above types, brand and application.
Other Advantages
Best Material
For
press brake tools
adopt 42CrMo and advanced processing technology. For punch press tools, we produce it with SKH-51 which can make the tools more durable and wear-resistant. For
shearing blades
& various
industrial cutters
, they are made from a special analysis of high carbon, high chrome tool steel.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the tools are standard. or it is 15-20 days if the tools is
special forming
shape.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
