Quick Details
-
Shelf life:
-
6 months
-
Specifications:
-
10ML/30ML
-
Product category:
-
LCP metal rubber
-
Chemical types:
-
Epoxy resin
-
Appearance:
-
Black liquid
-
Application material:
-
CCD / CMOS/VCM
-
Viscosity:
-
8500cPs
-
Density:
-
1.2
-
Hardness:
-
D88
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
AVENTK
-
Model Number:
-
1099T60
-
Shelf life:
-
6 months
-
Specifications:
-
10ML/30ML
-
Product category:
-
LCP metal rubber
-
Chemical types:
-
Epoxy resin
-
Appearance:
-
Black liquid
-
Application material:
-
CCD / CMOS/VCM
-
Viscosity:
-
8500cPs
-
Density:
-
1.2
-
Hardness:
-
D88
Products Description
|
Brand
|
AVENTK
|
Shelf life
|
6 months
|
|
Place of Origin:
|
Shanghai, China
|
Specifications
|
10ML/30ML
|
|
Product category
|
LCP metal rubber
|
Certification
|
ISO/RoHS/UL
|
|
Chemical types
|
Epoxy resin
|
Application field
|
It is designed for CCD/CMOS and VCM components of thermal sensors that require low curing temperatures. Excellent bonding strength
for LCP, metal, etc. |
|
Appearance
|
Black liquid
|
Application material
|
CCD / CMOS/VCM
|
|
Viscosity
|
8500cPs
|
Elongation at break
|
2.3%
|
|
Density
|
1.2
|
Tensile strength at break
|
34Mpa
|
|
Hardness
|
D88
|
Vitrification temperature
|
70℃
|
|
Thixotropic value
|
2.1
|
Linear shrinkage
|
0.8%
|
|
Flash point
|
＞93℃/200℉
|
Curing band
|
365nm
|
1099T60
is a heat-curable epoxy adhesive. The formula is based on a solvent-free epoxy system of one component products. It is designed for CCD/CMOS and VCM components of thermal sensors that require low curing temperatures. The glue can be cured in ultra-narrow gaps (below 10U). Excellent bonding strength for LCP, metal, etc.
