Quick Details
-
Dimension(L*W*H):
-
39*33*35CM
-
Weight:
-
16
-
Warranty:
-
1 year
-
Certification:
-
ISO9001,CE
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
wenxin
-
Model Number:
-
WX-168F
-
Dimension(L*W*H):
-
39*33*35CM
-
Weight:
-
16
-
Warranty:
-
1 year
-
Certification:
-
ISO9001,CE
Specifications and feature:
168F gasoline engine,single dylinder 4 stroke,OHV,air-cooled.
1.single cylinder,OHV,horizontal shaft,4 stroke gasoline engine
2.Hardening Crankshaft and Camshaft for longer life
3.compact and smart design,light weight,easy moving
4.easy recoil or electric start,convenient operation.
5.output form:can be 1:1 or 1/2 reduction gear
6.low RPM with strong torque
7.can be with oil cut alert
8.option: semi-dry,oil bath,dual air cleaner
9.can be with chroming processed muffler
10.Multiple applications,widely use of general machine
| Model | WX168F | WX173F | WX188F | WX190F |
| Engine Type | 4-Stroke,Single Cylinder, Air Cooling, OHV, Horizontal Shaft | |||
| Bore×Stroke (mm) | 68x54 | 73×58 | 88×64 | 90×64 |
| Displacement (cc) | 196 | 242 | 389 | 407 |
| Compression Ratio | 8.6:1 | 8.6:1 | 8.6:1 | 8.6:1 |
| Max. Power (Kw/ hp/rpm) | 4.8/6.5/3600 | 5.9 /8/3600 | 9.6/13/3600 | 11/15/3600 |
| Max.Torque (N.m) | 13.2 | 16.7 | 26.5 | 28 |
| Fuel Tank Capacity (L/Gal) | 3.6 | 6.5 | 6.5 | 6.5 |
| Oil Capacity (L/Gal) | 0.6 | 1.1 | 1.1 | 1.1 |
| fuel Consumption (g/Kw.h) | 360 | 325 | 325 | 325 |
| Ignition System | Transistorized Magneto Ignition | |||
| Starting Mode | Recoil Start/ Electric Key Start | |||
| Fuel Type | Gasoline (Petrol) | |||
| Recommended Oil | Summer: SAE 10W/30; Winter: SAE 15W/40 | |||
| Dimensions (L×W×H) (mm) | 390×330×350 | 515×420×470 | 515×420×490 | 515×450×490 |
| Net Weight (Kg) | 15 | 25 | 31 | 34 |
| Loading Qty.( 20 GP container) | 620 | 280 | 280 | 250 |
| Loading Qty.(40 GP container) | 1500 | 680 | 680 | 600 |
| Accessories | Spark Plug Wrench, belt roller,Tool Kit, Start Key for Electric Key Start | |||
