Quick Details
-
Place of Origin:
-
Fujian, China
-
Engine Model:
-
SC8D190.1G2
-
Rated Speed (rpm):
-
2200
Quick Details
-
Type:
-
Single Drum Roller
-
Power:
-
140kw
-
Weight:
-
18500kg
-
Place of Origin:
-
Fujian, China
-
Engine Model:
-
SC8D190.1G2
-
Rated Speed (rpm):
-
2200
Features of XGMA Hydraulic Vibratory Road Roller
1. Adopt the Shanghai
SC8D190.1G2
turbocharged diesel engine, which is reliable and conforms to the emission standard.
2.Hydraulic components are SAUER or REXROTH products, Vibratory bearings are imported from Sweden SKF or Germany FAG.
3
. The drive pump, vibration pump and steering pump are combined in series and connect with diesel engine directly, thus making the machine more compact and facilitating the maintenance.
4
. Its two amplitudes accommodate to various working conditions, with the front/rear drive and the continuous travel speed control.
5
. The spacious, comfortable, low-noise cab features thermal insulation, vibration reduction and provides virtually unobstructed all-around visibility.
6
. The three-stage braking system is highly safe and reliable.
7
. Optional pad-foot drum and air-conditioner to better suit customer's needs.
2. Main Technical Parameter
|
Description |
Unit |
XG6181 H |
|
|
Operating Weight |
kg |
18 5 00 |
|
|
Static Linear Load of Drum |
N/cm |
497 |
|
|
Vibration Frequency |
Hz |
28 /32 |
|
|
Theoretical Amplitude |
mm |
2.1 / 1.2 |
|
|
Centrifugal Force |
kN |
350 / 210 |
|
|
Drum Weight |
kg |
10 35 0 |
|
|
Min. Turning Radius |
mm |
6500 |
|
|
Max. Gradeability |
% |
35 |
|
|
Drum (D×W) |
mm |
φ1550×2130 |
|
|
Min. Ground Clearance |
mm |
3 6 5 |
|
|
Overall Dimensions (L×W×H) |
mm |
6 254 ×23 32 ×3 232 |
|
|
Travel speed |
Gear I |
km/h |
0-4.5 |
|
Gear II |
km/h |
0-6. 5 |
|
|
Gear III |
km/h |
0-10.3 |
|
|
Engine |
Model |
|
SC8D190.1G2 |
|
Rated Power |
kW |
140 |
|
|
Rated Speed |
r/min |
2200 |
|
|
Air condition |
|
|
Yes |
Our service
We are professional supplier of China construction machinery including all spare parts.
Please feel free to contact us if any request or questions. We will supply you the machinery with lowest price in China.
Sales Manager: Yake Liu
Mobile phone: +8615980814016
Whatsapp ID and Wechat ID:
+8615980814016
QQ: 502799183
Facebook: Liu Yake
Email: 502799183@ qq.com
spare parts as follows:
