Quick Details
-
Name:
-
Nozzle
-
Weight:
-
0.1Kg
-
Size:
-
60 mm
-
Material:
-
boron carbide
-
Usage:
-
Spray gun head,blasting nozzle
-
MOQ:
-
1PCS
-
Max. Pressure:
-
5000psi
-
Packing:
-
glue cover
Quick Details
-
Type:
-
Boron carbide nozzle
-
Application:
-
Sand blasting parts
-
Place of Origin:
-
Guangdong, China
-
Name:
-
Nozzle
-
Weight:
-
0.1Kg
-
Size:
-
60 mm
-
Material:
-
boron carbide
-
Usage:
-
Spray gun head,blasting nozzle
-
MOQ:
-
1PCS
-
Max. Pressure:
-
5000psi
-
Packing:
-
glue cover
Boron carbide materials
Boron carbide: is the hexagonal system. usually gray-black powder.
It's also called : black diamond B4C
It is one of the most rigid artificial materials known. It is light in weight, conductive in semiconductor, capable of absorbing neutrons without forming any radioisotope, with high grinding efficiency and no reaction with strong acid/alkali.
Compact boron carbide can be made into nozzles, boron carbide nozzles.
Mohs hardness: 9.36
Microhardness: 5400 ~ 6300kgf/mm
Density: 2.52 g/cm2
Boiling point: 3500 ℃
Melting point: 2450 ℃
flexure strength ≥ 400Mpa
Solubility: insoluble in water
Crystal structure: rhombohedral
Quality inspection project indicators: B4C >90%
Service life of nozzle :
|
material |
Alumina sand / H |
|||
|
Ceramic nozzle |
30-50 |
20-40 |
10-30 |
1-4 |
|
tungsten carbide nozzle |
600-1000 |
500-800 |
300-400 |
20-40 |
|
Silicon carbide nozzle |
800-1200 |
600-1000 |
400-600 |
50-100 |
|
Boron carbide nozzle |
2200-2800 |
2000-2500 |
1000-1500 |
600-1000 |
Nozzle size:
| Type | Model No. | Length(mm) | Φ O.D (mm) | Φ I.D(mm) |
| blasting nozzle | BA35-3 | 35 | 20 | 3 |
| BA35-4 | 35 | 20 | 4 | |
| BA35-5 | 35 | 20 | 5 | |
| BA35-6 | 35 | 20 | 6 | |
| BA35-8 | 35 | 20 | 8 | |
| BA35-10 | 35 | 20 | 10 | |
| BA35-12 | 35 | 20 | 12 | |
| BA45-5 | 45 | 20 | 5 | |
| BA45-6 | 45 | 20 | 6 | |
| BA45-8 | 45 | 20 | 8 | |
| BA45-10 | 45 | 20 | 10 | |
| BA45-12 | 45 | 20 | 12 | |
| BA55-8 | 55 | 20 | 8 | |
| BA60-6 | 60 | 20 | 6 | |
| BA60-8 | 60 | 20 | 8 | |
| BA60-10 | 60 | 20 | 10 | |
| BA60-12 | 60 | 20 | 12 | |
| BA80-6 | 80 | 20 | 6 | |
| BA80-8 | 80 | 20 | 8 | |
| BA80-10 | 80 | 20 | 10 | |
| BA80-12 | 80 | 20 | 12 | |
| BA82-10 | 82 | 20 | 10 | |
| BA82-12 | 82 | 20 | 12 | |
| blasting nozzle | B454 | 45 | 15 | 4 |
| B455 | 45 | 15 | 5 | |
| B456 | 45 | 15 | 6 | |
| B458 | 45 | 15 | 8 | |
| B556 | 55 | 15 | 6 | |
| B558 | 55 | 15 | 8 |
