Quick Details
-
Rated Voltage:
-
400V
-
Rated Current:
-
1949A
-
Speed:
-
1500rpm
-
Frequency:
-
50Hz
-
Engine:
-
Googol
-
Alternator:
-
Googol, Faraday, Marathon, Stamford, etc
-
Controller:
-
Deep Sea, etc
-
Application Area:
-
Industry Project, Hospital, Hotel, etc
-
Certificate:
-
CE, ISO, etc
-
Advantage:
-
Fuel Efficiency, Anti-vibration, Low Noise and Pollution
-
Optional:
-
ATS, Silent Canopy, Moving Trailer, Water&Oil Heater, etc
-
Color:
-
Yellow or as Needed
-
Warranty:
-
1 year or 1000 working hours
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Honny Power
-
Model Number:
-
HGGM1350
-
Rated Voltage:
-
400V
-
Rated Current:
-
1949A
-
Speed:
-
1500rpm
-
Frequency:
-
50Hz
-
Engine:
-
Googol
-
Alternator:
-
Googol, Faraday, Marathon, Stamford, etc
-
Controller:
-
Deep Sea, etc
-
Application Area:
-
Industry Project, Hospital, Hotel, etc
-
Certificate:
-
CE, ISO, etc
-
Advantage:
-
Fuel Efficiency, Anti-vibration, Low Noise and Pollution
-
Optional:
-
ATS, Silent Canopy, Moving Trailer, Water&Oil Heater, etc
-
Color:
-
Yellow or as Needed
-
Warranty:
-
1 year or 1000 working hours
| Genset Model | HGGM1350 | |
| Genset Prime Output | kW/kVA | 1080/1350 |
| Genset Continuous Output | kW/kVA | 1024/1280 |
| Engine Model | JTA3240-G1 | |
| Alternator Model | GP1563-4P | |
| Alternator Efficiency at Prime Output | ≥ | 96.8% |
| Genset Frequency | Hz | 50 |
| Alternator Prime Output | kW | 1250 |
| Temperature rising’s class | F class(105℃) | |
| Insulation class | H | |
| Quantity of Alternator’s Bearing | 1 | |
| Rating Voltage | V | 400 |
| Power Factor | 0.8 | |
| Bore | mm | 170 |
| Stroke | mm | 195 |
| Configuration | Vee | |
| No. of Cylinders | 12 | |
| Air Ration | λ | 1.6 |
| Genset Size (LxWxH) | mm | 4200x1600x2400 |
| Genset Weight | kg | 9200 |
