Quick Details
-
Size:
-
9500-13500mm*2500-2600mm*3200-4000mm
-
Place of Origin:
-
China
-
Shipment Term:
-
By Bulk Cargo,RORO or 40HQ Containers
-
Dimension:
-
9500-13500mm*2500-2600mm*3200-4000mm
-
Tare Weight:
-
About 8000KGS-12800KGS
-
Capacity:
-
20000-60000 Liters
-
Compartments:
-
Optional
-
Discharge Valve:
-
Diameter is 3 or 4 inch
-
Kingpin:
-
JOST2.00 or 3.5 inch
-
Main Beam:
-
Steel Q345 or Aluminium Alloy
-
Leaf Spring:
-
90(W)*13(Thickness) mm*10 Layer or 100mm*12mm*12
-
Suspension:
-
Mechanical Suspensions/Germany or America type/Air suspension
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
20000-60000 Liters
-
Brand Name:
-
Yuetong
-
Size:
-
9500-13500mm*2500-2600mm*3200-4000mm
-
Place of Origin:
-
China
-
Shipment Term:
-
By Bulk Cargo,RORO or 40HQ Containers
-
Dimension:
-
9500-13500mm*2500-2600mm*3200-4000mm
-
Tare Weight:
-
About 8000KGS-12800KGS
-
Capacity:
-
20000-60000 Liters
-
Compartments:
-
Optional
-
Discharge Valve:
-
Diameter is 3 or 4 inch
-
Kingpin:
-
JOST2.00 or 3.5 inch
-
Main Beam:
-
Steel Q345 or Aluminium Alloy
-
Leaf Spring:
-
90(W)*13(Thickness) mm*10 Layer or 100mm*12mm*12
-
Suspension:
-
Mechanical Suspensions/Germany or America type/Air suspension
Products Description
|
Yuetong Automobile Industry (Tianjin) Co.,Ltd.
|
|
|
|
Model number
|
LYT9401GRY
|
|
|
|
|
|
|
Capacity
|
20000-60000 Liters
|
|
|
Tank Body：
|
|
|
|
|
|
|
|
Tank Shell
|
5mm or 6mm/ Q235 Carbon steel plate/Aluminium Alloy 5083/5182/5454/Stainless Steel304/316
|
|
|
Bulkhead & end plate
|
6mm or 7mm/Q235 Carbon steel plate/Aluminium Alloy 5083/5182/5454/Stainless Steel 304/316
|
|
|
Manhole Cover
|
stainless steel,aluminum alloy manhole ,diameterφ500mm,2/3/4 pieces
|
|
|
Discharge Valve
|
Diameter is 3 or 4 inch
|
|
|
Compartments
|
Optional
|
|
|
Discharge Pipe
|
4”Rubber tube,2 pieces , 6m/each
|
|
|
Chasis
|
|
|
|
Main Beam
|
Steel Q345 or Aluminium Alloy
|
|
|
Axle
|
13/16T,FUWA/BPW brand
|
|
|
Landing gear
|
28 ton two speed telescopic manual landing gear
|
|
|
King Pin
|
JOST2.00 or 3.5 inch
|
|
|
Suspension
|
Mechanical Suspensions/Germany or America type/Air suspension
|
|
|
Brake
System |
WABCO RE6 replay vavle;Spring brake chamber,2 pieces of 45Lair tanks
|
|
|
Rim
|
9.00-22.5/8.00-20/8.5-20
|
|
|
Tire
|
12.00R22.5/315 80R22.5/11.00R20/12.00R20 Brand can be Optional
|
|
|
ABS
|
Optional
|
|
|
Electrical system
|
Voltage: 24 Volt
Receptacle: 7 way socket standard, China Front lamp: White Side marker lamp: White & Red |
|
|
Welding Standard
|
All welding are to be done by qualified welder per applicable national standard
|
|
|
Tool box
|
1 pc
|
|
|
Reflector
|
Per customer requirement
|
|
|
Painting
|
Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Color advised by customer
|
|
|
Shipping Terms
|
1 unit per package by bulk vessel or roro ship
|
|
