Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Haidike
-
Model Number:
-
HDK-600ZZD
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
710*900*870(mm)
-
Weight:
-
96kg
-
Core Components:
-
Motherboard
-
Max Speed:
-
30-160pcs/min
-
Pdoduct name:
-
All-in-one bag making machine
-
Product model:
-
HDK-600ZZD
-
Power supply:
-
220V 50/60Hz
-
Cutting length(mm):
-
0.1-99999.9mm
-
Cutting speed:
-
30-160pcs/min
-
Feeding width:
-
1-580mm
-
Cutting precision:
-
0.1mm
-
Feeding motor:
-
stepper motor
-
Cutter motor:
-
AC motor
-
Cutter material:
-
High-speed steel
Quick Details
-
Machine Type:
-
Bag Forming Machine
-
Bag Type:
-
Plastic bag
-
Material:
-
Plastic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Haidike
-
Model Number:
-
HDK-600ZZD
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
710*900*870(mm)
-
Weight:
-
96kg
-
Core Components:
-
Motherboard
-
Max Speed:
-
30-160pcs/min
-
Pdoduct name:
-
All-in-one bag making machine
-
Product model:
-
HDK-600ZZD
-
Power supply:
-
220V 50/60Hz
-
Cutting length(mm):
-
0.1-99999.9mm
-
Cutting speed:
-
30-160pcs/min
-
Feeding width:
-
1-580mm
-
Cutting precision:
-
0.1mm
-
Feeding motor:
-
stepper motor
-
Cutter motor:
-
AC motor
-
Cutter material:
-
High-speed steel
| Pdoduct name | All-in-one bag making machine |
| Product model | HDK-600ZZD |
| Power supply | 220V 50/60Hz |
| Cutting length(mm) | 0.1-99999.9mm |
| Cutting speed | 30-160pcs/min |
| Feeding width | 1-580mm |
| Cutting precision | 0.1mm |
| Weight | 96kg |
| Size (L×W×H) | 710*900*870(mm) |
| Feeding motor | Stepper motor |
| Cutter motor | AC motor |
| Cutter material | High-speed steel |
| Heat sealing method | Pneumatic |
Features
1. A wide range of applications, suitable for the production of various plastic bags such as PE flat bags, PVC heat shrinkable bags, anti-static bags, packaging bags, OPP bags, etc.
2. The adjustable speed motor cooperates with the photoelectric sensor to realize automatic unwinding and synchronous cutting, with faster speed, higher efficiency and more accurate precision.
3. The machine adopts compact design, smaller volume, and is equipped with all-in-one foot cup casters, which can be moved and installed at any time.
4. Adopting a spring-type feeding mechanism with an adjustable angle receiving table, no matter the thickness of the material can be collected neatly, saving labor.
5. Humanized design, simple operation, stable performance and easy maintenance.
6. The heat-sealing device can be disassembled and replaced, and the temperature is adjustable, suitable for sealing various materials and thickness materials.
Material application
It is suitable for cutting various roll materials such as PE film, roll film, PVC film, PET film, OPP film, PP film, heat shrinkable film, anti-static film, printing and packaging film.
Cut samples
It is suitable for cutting various plastic bags such as PE flat bags, PVC heat shrinkable bags, PET bags, OPP bags, PP bags, anti-static bags, printed packaging bags, roll film packaging bags, etc.
Adjustable cutting length, speed, sealing position, sealing time, cooling time and sealing mould temperature
Product principle:
1. Automatic group accumulation and total cumulative count
2. Batch pause and delay time can be set
3. There are various manual operations for debugging
4.Fully automatic cutting of various plastic bags, flat bags, heat shrinkable films, electrostatic bags and other materials
5. High-speed feeding, controlled by microcomputer program with an accuracy of 0.1mm
6. High-speed stepping motor accurately controls cutting length and speed
7. Cutting time protection; total setting; sub-setting; adjustable timeout
8. The cutter speed is adjustable, all Chinese LCD display, export or foreign companies can be customized English version
9. The length and speed are arbitrarily adjustable, fully automatic cutting and automatic feeding, completely liberating labor
10.LCD large screen intuitive Chinese display, simple and convenient operation; using special mechanical structure and special tools,With special software control, it solves the problem of uneven cutting in other manufacturers, reaching the level of the slit and the length
11. Fast feeding speed, high cutting force, high cutting efficiency, stable performance, cutting all kinds of hard and thick materials, high cutting precision and straight cut
12. The heat sealing device can be disassembled and replaced, and the temperature is adjustable, which is suitable for sealing various materials and thickness materials.
