Quick Details
-
Color:
-
fluorecent
-
Product name:
-
fluorecent yellow 131SC
-
Application:
-
engine leak detection
-
Application 2:
-
automobile refrigeration system leak detection
-
sample:
-
free
-
Appearance:
-
liquid
-
Flash point:
-
185 degree
-
Density (LBS /Gal):
-
7.6
-
Maximum excitation value:
-
494 + 5 nm
-
Maximum emission value:
-
535 + 5 nm
Quick Details
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
JQ
-
Model Number:
-
FLUORESCENT YELLOW 131 sc
-
Color:
-
fluorecent
-
Product name:
-
fluorecent yellow 131SC
-
Application:
-
engine leak detection
-
Application 2:
-
automobile refrigeration system leak detection
-
sample:
-
free
-
Appearance:
-
liquid
-
Flash point:
-
185 degree
-
Density (LBS /Gal):
-
7.6
-
Maximum excitation value:
-
494 + 5 nm
-
Maximum emission value:
-
535 + 5 nm
Fluorescent Yellow 131 sc oil soluble Fluorescent tracer agent of leak detection
As a global, diversified and leading chemical companies operating, dow chemical has more than 5000 kinds of products, as one of them, Fluorescent Yellow 131 sc Liquid Dye oil soluble Fluorescent agent has been the world's major automotive vehicles, engineering machinery and component manufacturers recognized and used.
Spectronics' tp-3400 fluorescence tracer can completely replace Spectronics' tp-3400 series.
Fluorescent Yellow 131 SC Liquid Dye is a kind of highly active ring of hydrogenated alkyl Solvent system containing Solvent Red 175 concentrated Solvent soluble dyes. The product can show dark Liquid and the vast majority of oil and organic products are good miscibility. The Solvent viscosity control and standardized role. Fluorescent Yellow 131 SC used as gasoline, diesel engine, hydraulic system, transmission system, steering system and industrial pipeline leak. Fluorescent Yellow 131 sc is a leading leak detection of liquid dyes. More than 30 years ago, Fluorescent Yellow 131 sc were invented to meet and hydraulic machine manufacturers to quickly and reliably in the lubrication system, hydraulic system and fuel system to detect leaks. Large .
Flash point (ASTM D - 3278 > 85 ° C) : 185 ° F
Oil solubility: complete dissolution
Product specification:
Fluorescein strength (compared with standard): 100 + 5%
Insoluble matter (filtration method): 0.2% Maximum
Water content (Karl fischer method): <0.5%
Application Suggestions:
There are two ways to add dye to the engine :1. Before engine test, the engine oil and dye can be mixed in advance and added to the engine.
2. After the fuel is added to the engine, the dye is added directly to the engine fuel tank.
High intensity fluorescents (100-125 W emitting at 365nm) were used to detect the leakage.
Flash point (ASTM D - 3278 > 85 ° C) : 185 ° F
Oil solubility: complete dissolution
Product specification:
Fluorescein strength (compared with standard): 100 + 5%
Insoluble matter (filtration method): 0.2% Maximum
Water content (Karl fischer method): <0.5%
Recommended dosage:
From the following recommendations, the exact amount of injection is based on the desired color intensity and background color.
Hydraulically actuated fluid :500 to 2000 PPM
Automotive engine oil :500 PPM
Diesel engine oil :700 to 2000 PPM
Fuel: 700 PPM
Remove:
It is easy to remove the dye from the metal surface by wiping it with a chlorine-containing solvent, paraffin oil or metal cleaner.
Packing:
18 kg/b
All specific ingredients are included in or exempted from China's existing list of chemicals; Comply with us TSCA regulations. Fluorescent Yellow 131 sc is lowest cost efficient leak detection dye, specially to with you to improve your profitability and quality system.
