Quick Details
-
Warranty(Year):
-
1-Year
-
Input Voltage(V):
-
3.7V
-
Working Time (hours):
-
100000
-
Product Weight（kg）:
-
0.55
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
HUC
-
Model Number:
-
KL5M / KL8M / KL12M
-
Model:
-
KL5M / KL8M / KL12M
-
Rated capacity:
-
6.6Ah / 8.8Ah / 12.4Ah
-
Rated voltage:
-
3.7V
-
Main light life span:
-
100000 h
-
Auxiliary light life span:
-
40000 h
-
Short Circuit Protect time:
-
<320s
-
Life span of the battery:
-
1200 cycles
-
Charging by NWB-25:
-
4h / 5h / 6h
-
Main cable:
-
1.4M / 1.65M
-
Dimensions:
-
95x38x84mm / 95x38x102mm / 95x38x102mm
Quick Details
-
Lifespan (hours):
-
100000
-
Power Source:
-
rechargeable battery
-
Lamp Body Material:
-
ABS
-
Warranty(Year):
-
1-Year
-
Input Voltage(V):
-
3.7V
-
Working Time (hours):
-
100000
-
Product Weight（kg）:
-
0.55
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
HUC
-
Model Number:
-
KL5M / KL8M / KL12M
-
Model:
-
KL5M / KL8M / KL12M
-
Rated capacity:
-
6.6Ah / 8.8Ah / 12.4Ah
-
Rated voltage:
-
3.7V
-
Main light life span:
-
100000 h
-
Auxiliary light life span:
-
40000 h
-
Short Circuit Protect time:
-
<320s
-
Life span of the battery:
-
1200 cycles
-
Charging by NWB-25:
-
4h / 5h / 6h
-
Main cable:
-
1.4M / 1.65M
-
Dimensions:
-
95x38x84mm / 95x38x102mm / 95x38x102mm
Hunan Huachuang Lighting Electrical Appliance Co., Ltd
has been a professional manufacturer of mining lighting equipment for 20 years. Our main products include: mining lamps,headlights, explosion-proof lighting lamps, digital gas alarm lamps, tunnel lamps, mining charging racks (charging cabinets), andmining command and communication systems; Production and sales of injection molded shells and die-casting shells. The product is explosion-proof and has complete coal safety certification.
|
Features
|
KL5M
|
|
|
KL8M
|
|
|
KL12M
|
|
|
||||||||
|
Working time version
|
Standard
|
Long
|
Super-long
|
Standard
|
Long
|
Super-long
|
Standard
|
Long
|
Super -long
|
||||||||
|
Rated capacity
|
6.6Ah
|
|
|
8.8Ah
|
|
|
12.4Ah
|
|
|
||||||||
|
Rated voltage
|
3.7V
|
|
|
|
|
|
|
|
|
||||||||
|
Continuous working time
|
13h
|
16h
|
24h
|
13h
|
16h
|
24h
|
13h
|
16h
|
24h
|
||||||||
|
Main light LED working voltage
|
3.0V
|
|
|
|
|
|
|
|
|
||||||||
|
Main light LED working current
|
580mA
|
430mA
|
340mA
|
800mA
|
580mA
|
430mA
|
1000mA
|
800mA
|
580mA
|
||||||||
|
Main light power
|
1.8W
|
1.3W
|
1W
|
2.4W
|
1.8W
|
1.3 W
|
3.0W
|
2.4W
|
1.8W
|
||||||||
|
Main light luminous flux
|
235 Lm
|
178Lm
|
148Lm
|
301Lm
|
235Lm
|
178Lm
|
359Lm
|
301Lm
|
235Lm
|
||||||||
|
Lamp lighting Degree (initial lighting degree)
|
16000 Lux
|
11000 Lux
|
10000 Lux
|
23000 Lux
|
16000 Lux
|
11000 Lux
|
25000 Lux
|
23000 Lux
|
16000 Lux
|
||||||||
|
Main light life span
|
100000 h
|
|
|
|
|
|
|
|
|
||||||||
|
Auxiliary light Power
|
0.4W
|
|
|
|
|
|
|
|
|
||||||||
|
Auxiliarylight life span
|
40000 h
|
|
|
|
|
|
|
|
|
||||||||
|
Short Circuit Protect time
|
＜320μs
|
|
|
|
|
|
|
|
|
||||||||
|
Life span of the battery (recharges)
|
1200 cycles (in reasonable working conditions)
|
|
|
|
|
|
|
|
|
||||||||
|
Charging by NWB-25
|
4h
|
|
|
5h
|
|
|
6h
|
|
|
||||||||
|
Main cable
|
1.4M / 1.65M
|
|
|
|
|
|
|
|
|
||||||||
|
Dimensions (size of box)
|
95x38x84mm
|
|
|
95x38x102mm
|
|
|
95x38x102mm
|
|
|
||||||||
|
Weight
|
500g
|
|
|
550g
|
|
|
550g
|
|
|
||||||||
With professional and technical personnel, dozens of sets of advanced equipment, adapt to mass production, fast shipment. There are special CNC workshop, milling machine workshop, mold workshop, spray workshop, injection workshop, die casting workshop,assembly workshop, charging and testing workshop, R & D design room, office area and so on.
