Quick Details
-
EINECS No.:
-
226-171-3
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
JIA GU
-
Model Number:
-
HY584
-
Type:
-
silicone sealant
-
Product name:
-
silicone potting compound
-
Color:
-
white/transparent
-
Keywords:
-
silicone potting
-
Feature:
-
Eco-friendly
-
Main material:
-
silicone
-
Application range:
-
electronic
-
Advantage:
-
anti-yellowing,proper adhesive ability
-
Component:
-
Two component
-
A/B component viscosity (Pa.S):
-
4.5~7.5/0.4~0.5
-
Density (g/cm3) A/B::
-
1.2/1.03
Quick Details
-
CAS No.:
-
9016-00-6
-
Other Names:
-
RTV-2 silicone potting compound
-
MF:
-
C2H6OSi
-
EINECS No.:
-
226-171-3
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
JIA GU
-
Model Number:
-
HY584
-
Type:
-
silicone sealant
-
Product name:
-
silicone potting compound
-
Color:
-
white/transparent
-
Keywords:
-
silicone potting
-
Feature:
-
Eco-friendly
-
Main material:
-
silicone
-
Application range:
-
electronic
-
Advantage:
-
anti-yellowing,proper adhesive ability
-
Component:
-
Two component
-
A/B component viscosity (Pa.S):
-
4.5~7.5/0.4~0.5
-
Density (g/cm3) A/B::
-
1.2/1.03
Product Display
HY584 silicone potting sealant is a two-component, room temperature curing, condensation and dealcoholization type of silicone potting material. Self-leveling, high and low temperature resistance, excellent aging resistance, insulation, moisture resistance and shock resistance. Used in various bonding and sealing of electronic components.
Product Features
1. Solvent-free, environmentally friendly and low-carbon
2. Excellent weather resistance, aging resistance, UV resistance
3. It is insulation, moisture-proof, shock- resistance
4. Suitable for potting and sealing of electronic components
5. Non-corrosive
Product Paramenters
|
Model
|
HY584T
|
HY584P
|
HY584Z
|
HY584H
|
|||
|
Color A/B
|
Colorless and transparent
|
White etc./ transparent
|
White etc./ transparent
|
Off-white/ transparent
|
|||
|
Density (g/cm3)A/B
|
0.95~1.05
|
1.3/1.03
|
1.3/1.03
|
1.3/1.03
|
|||
|
A component viscosity (Pa.S)
|
1.5~2.5
|
5.5~11
|
7.5~13
|
7.5-13
|
|||
|
B component viscosity (Pa.S)
|
0.01~0.1
|
0.01~0.1
|
0.01~0.1
|
0.01-0.1
|
|||
|
Viscosity after mixing (Pa.S)
|
0.5~1.5
|
2.5~5.5
|
2.5~6.5
|
2.5~6.5
|
|||
|
Operation time (min)
|
30~90
|
40~120
|
40~120
|
40~120
|
|||
|
Full curing time (h)
|
24
|
24
|
24
|
24
|
|||
|
Shore Hardness (Shore A)
|
10~30
|
20~40
|
20~50
|
20~50
|
|||
|
Shear strength (MPa)
|
0.8
|
0.8
|
0.8
|
0.8
|
|||
|
Thermal conductivity (W/m•k)
|
0.3
|
0.3
|
0.7
|
2.0
|
|||
|
Flame retardant grade (UL94)
|
HB
|
HB
|
V0
|
HB
|
|||
|
Dielectric strength (kv/mm)
|
≥18
|
|
|
|
|||
|
Volume resistance (Ω•cm)
|
≥1.0×10 14
|
|
|
|
|||
|
Applicable temperature (℃)
|
-60~200
|
|
|
|
|||
HY584T is suitable for potting and sealing of electronic components with
transparency requirements
.
HY584P is suitable for potting and sealing of
electronic components.
HY584Z is suitable for various potting and sealing of electronic components that have
thermal conductivity and flame retardant requirements
.
HY584H is suitable for potting and sealing of electronic components with
high thermal conductivity requirements.
Cooperation partners
Factory display
Zhengzhou Huayu Technology Co., Ltd.
It is a professional manufacturer of adhesives. The products involve organic silicon, polyurethane, polysulfide glue, epoxy glue, anaerobic glue, solvent rubber and other fields, and have been used in the field of solar photovoltaic module manufacturing for many years. The products meet the special requirements of the photovoltaic industry for polymers: high adhesion, UV resistance, yellowing resistance, waterproof and moisture-proof, hail resistance, insulation performance and long-term outdoor service life. The products have passed SGS, CE, UL and other safety certifications.
Certifications
Exhibition Exchange
Product packaging
|
A component packed in 10kg/barrel. Barrel mouth diameter: 270mm, height 295mm.
|
B component packed in 1kg/plastic bottle.14 bottle/carton. Safety and health
|
|
Number of whole pieces：
|
14 bottle/carton
|
FAQ
Q1. Are you manufacturer or trading company?
A: Yes, we are manufacturer, founded in 1997. We can provide you direct prices. Our plant is 1.5 hours away from Zhengzhou City, in the central China. Welcome to visit our factory.
Q2. Can I get a sample before order?
A: Yes, of course. Generally we offer free samples with freight collect, and will send sample within 2 days, you can get it
within 5~7 days.
Q3. What’s the delivery time?
A: It’s about 5~10days according to order quantity after payment. For example, the producing time is 5 days for 1000 tons sealant.
Q4. How do you guaranty the quality?
A: Our products meet the standard CE, Rosh, UL, etc. And we test the each batch of goods before delivery and keep all the order retention samples for 6~12 months.
Q5. Do you accept Private Label?
A: Yes. OEM or ODM orders are accepted.
Q6. Can I be your agent?
A: Sure, we are looking for agent all over the world.
