Quick Details
-
Material:
-
C80/16Mn/30MnB
-
Color:
-
Customer's Request
-
Payment:
-
T/T
-
MOQ:
-
1PC
-
Weight:
-
50kgs
-
Certification:
-
ISO9001:2015/SGS
-
Delivery time:
-
7-35 Days
-
Temperature:
-
-20°C
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Yassian
-
Application:
-
Excavator Motorgrader Bulldozer Loader Attachment
-
Material:
-
C80/16Mn/30MnB
-
Color:
-
Customer's Request
-
Payment:
-
T/T
-
MOQ:
-
1PC
-
Weight:
-
50kgs
-
Certification:
-
ISO9001:2015/SGS
-
Delivery time:
-
7-35 Days
-
Temperature:
-
-20°C
Product Description
| Grader blade | |||
| Model No | 4T2244 | Packing | Plywood pallet |
| Material | High-carbon steel (C80); Boron steel (30MnB) | G.W. | 68 KGS |
| Size | 1828 (6ft)*203*25 13holes*5/8" | N.W. | 68.5 KGS |
| Hardness | HB280-500 | Corol | Customer Required |
| Delivery time | 25-30days (one container) | Logo | Customer Required |
| Color |
Customer Required |
MOQ | 1pc |
| Logo | Customer Required | Loading Port | Ningbo,Shanghai |
| Certificates | ISO9001: 2015, SGS | Warranty | 24 months |
| Sample | Description | Weight (kg) | Model Application |
| 5D9553 | DBC Grader Blade 1828*152*16 13*5/8" | 29 | 12G,12H,14T,112T,120,120G,120H,130G,135H,140H,140G,12F,322B |
| 5D9554 | DBC Grader Blade 2133*152*16 15*5/8" | 34 | 12G,12H,120G,120H,130G,16T,140H,135H,143H,12F |
| 5D9558 | DBC Grader Blade 1828*203*19 13*5/8" | 50 | 12G,12H,14T,112T,120,120G,135H,140G,140,152X,143H,140H,163H,160K,140K,12F |
| 5D9559 | DBC Grader Blade 2133*203*19 15*5/8" | 59 | 12G,12H,120G,120H,16T,140G,140K,143H,140H,135H,12F |
| 5D9556 | DBC Grader Blade 1828*152*19 13*5/8" | 35.5 | 12G,12H,14T,112T,120,120G,120H,130G,135H,12F |
| 5D9557 |
DBC Grader Blade 2133*152*19 15*5/8" |
42 | 12G,12H,120G,120H,130G,16T,12F |
| 5D9562 | DBC Grader Blade 1828*203*16 13*5/8" | 42 | 12G,12H,14T,112T,120,120G,120H,135H,140G,140,152X,12F,140H,143H,135H,12F |
| 5D9561 | DBC Grader Blade 2133*203*16 15*5/8" | 49 | 12G,12H,120G,120H,16T,140G,143H,140H,135H,163H,160H,12F |
| 4T2244 | DBC Grader Blade 1828*203*25 13*5/8" | 68 | 3304,3306,120G,12G,130G,140G |
| 4T2242 | DBC Grader Blade 2133*203*25 15*5/8" | 79 | 3304,3306,120G,12G,130G,140G |
| 7D1158 | DBC Grader Blade 2133*203*16 15*3/4" | 49 | 14G,14H,120M,160K,160M,163H,160H,14M,140K,12M,143H304,3306,120G,12G,130G,140G |
| 7D1576 | DBC Grader Blade 1828*203*19 13*3/4" | 50 | 12M,120K2,120K,120M,143H,12K,160M,163H,140M,140K,160H, |
| 7D1577 | DBC Grader Blade 2133*203*19 15*3/4" | 59 |
114G,14H,12M,143H,12K,140K2,14M,140M,163H,160M,140K,120M,120K,160H,160K,160HNA,
120M2AWD,160M3,12M2,160M2AWD,12M2AWD,120K2,12M,140M2,120M2,160M2,143H,14LAWD, 140M3,140K,140MAWD,14H,160MAWD,120MAWD,140HNA,160H,12HNA,12M3,14M3 |
| 4T2231 | DBC Grader Blade 2133*203*19 15*3/4" | 68 | 18M3,16H |
| 4T2233 | DBC Grader Blade 2133*203*25 15*3/4" | 79 | 3304,3306,3406,130G,14G,16G,12G,140G |
| Sample And so on | |||
