Products Description
SKU:
XB004910
Functional characteristics
1. Non-contact detection; Moving target detection.
2. The transmission frequency of the module is 10.525GHZ, which can be widely used in commercial and industrial automatic control fields
3. Different frequency range standards are available :-UK,-F. Advanced low-power PHEMT oscillator
4. Independent transmit and receive path, can obtain maximum gain, single channel operation.
5. High sensitivity, high flexibility, low cost, operating distance up to 20 meters
6. Not affected by temperature, humidity, noise, airflow, dust, light, etc., suitable for harsh environment;
7. Strong anti-RF interference ability, stable performance; Fast response and high sensitivity.
8. The output power is only 5mW, which is not harmful to human body;
9. Remote detection range up to 20 meters (default 0.2-10 meters continuously adjustable).
10. Small size, easy to install.
11. Radar waves can penetrate non-metallic objects, such as wood, glass, plastic, fiber fabrics, etc., unless there is a concrete wall and metal plate can be intercepted.
12. The best detection is when a person or object is moving towards the sensor!
two Technical parameters:
Type number: XZG-WB-10G-3
Size: 7.1*3.8*2.3cm
Electric voltage: 8-25V DC
Working current: 30ma
Induction Angle: 170 degrees (horizontal 95° Vertical 75°)
Operating temperature: -20°~ +55°
Frequency: 10.525GHZ
Detection distance: 0.2-12m continuously adjustable (fixed distance or adjustable range can be customized)
Output delay time: 1-300 seconds continuous adjustable, (fixed delay time can be customized)
Power delay start time: 10 seconds. (Different delay time can be customized) Note: This function is a delay of about 10 seconds after power-on time to sense and output signal, such as when used for alarm, it will not alarm once powered on to avoid noise.
Use: automatic doors, automatic lights, elevators, advertising machines, security alarms, industrial automatic control and other fields.
Three. Note:
1. Live operation is strictly prohibited, so as to avoid action errors, wrong connection, burnt circuit or electric shock; During operation, avoid touching the sensor surface of the probe with hands or tools to prevent electrostatic damage to the module probe.
2, avoid installation in the sun and rain places to prevent damage or affect the service life.
3, try to install far away from the magnetic field and vibration of the equipment, so as to avoid wrong action.
4, try to install away from the movement of objects (such as fans) at the same time is not suitable for use in the field environment, when used in the field environment next to shaking trees or larger animal activities, as well as rain drops may be induced to misaction.
5. The module can be installed on the ceiling or against the wall. The height of the wall installation is about 1.5-3 meters from the ground, and the induction surface of the module should form a depression Angle with the detected area when the height of more than 2 meters is installed against the wall.
The different Angle of installation will have a certain impact on the induction Angle and induction distance, please be sure to put the induction surface directly to the detected area when installing, and the induction head should be as straight as possible with the area to be detected.
The package includes:
1X 10GHz microwave radar sensor module
1X XH2.54-2P cable
1X XH2.54-3P cable
|
