Quick Details
-
Power Source:
-
Electric, Solar
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Babysun
-
Model Number:
-
1
-
Power supply:
-
220VAC
-
Item:
-
Non Pressure Solar Water Heater Controller Thermosiphon M-7
-
Product name:
-
solar water heating controller
-
advantage1:
-
Constant Temperature Heating
-
advantage2:
-
Model selection
-
advantage3:
-
Auto-control Booster Pump
Quick Details
-
After-sales Service Provided:
-
None
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Commercial, Household
-
Power Source:
-
Electric, Solar
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Babysun
-
Model Number:
-
1
-
Power supply:
-
220VAC
-
Item:
-
Non Pressure Solar Water Heater Controller Thermosiphon M-7
-
Product name:
-
solar water heating controller
-
advantage1:
-
Constant Temperature Heating
-
advantage2:
-
Model selection
-
advantage3:
-
Auto-control Booster Pump
China solar water heater controller,solar water heater microcomputer controller,intelligent controller for solar water heater
Product Overviews
|
Main functions
|
|
|
|
|||
|
Power on Self Test
|
|
Time Display
|
|
|||
|
Water Temperature Display
|
|
Water Level Display
|
|
|||
|
Water Level Preset
|
|
Water Temperature Preset
|
|
|||
|
Water Fill When Lack
|
|
Automatic Stop Water Fill When Full
|
|
|||
|
Manual Water Fill
|
|
Three Time Fixed Time Water Fill
|
|
|||
|
Temperature-controlled Water Fill
|
|
Constraint Water Fill
|
|
|||
|
Manual Heating
|
|
Constant Temperature Heating
|
|
|||
|
Three Time Heating
|
|
Leakage Protection
|
|
|||
|
Tube Defrost
|
|
Model selection
|
|
|||
|
Power Failure Memory
|
|
High Temperature Cut-off
|
|
|||
|
Dry Heating Protection
|
|
Water Fill in Low Water Pressure
|
|
|||
|
Auto-control Booster Pump
|
|
Overflow Protection
|
|
|||
Product Parameters
|
Main Technology Parameters
|
|
|
|
|
||||
|
Power Supply
|
|
220VAC±10% 50Hz
|
|
|
||||
|
Power Dissipation
|
|
＜ 5W
|
|
|
||||
|
Temperature Measuring Range
|
|
0～99℃
|
|
|
||||
|
Temperature Measuring Accuracy
|
|
±1℃
|
|
|
||||
|
Temperature Control Accuracy
|
|
±1℃
|
|
|
||||
|
Water Level Grading
|
|
Five-grade percentage figures display
|
|
|
||||
|
Power of Controllable Water Pump or Ribbon Heater
|
|
≤ 500W
|
|
|
||||
|
Power of Controllable Electric Heating Equipment
|
|
≤1500W
|
|
|
||||
|
Leakage Working Current
|
|
≤10mA 0.1s
|
|
|
||||
|
Parameter of Solenoid Valve
|
|
Direct current DCl2V, pressure or no-pressure valve is optional.
|
|
|
||||
|
Working Pressure of Pressure Valve
|
|
0.02MPa～0.8MPa, suitable direct water supply
|
|
|
||||
|
Working Pressure of No-pressure Valve
|
|
0.005MPa～0.5MPa, suitable to water tank water supply or low water pressure water supply
|
|
|
||||
|
Ultra-big color screen with Low Power Dissipation
|
|
＜ 0.5W
|
|
|
||||
|
Size of the Main Frame
|
|
210×145×47.5mm
|
|
|
||||
