Quick Details
-
Panel Size:
-
500x1000, 500x1000
-
Place of Origin:
-
Guangdong, China
-
name:
-
P3.91 led display screen
-
Power:
-
AC-100-240V
-
Brand:
-
Hosen
-
Made in:
-
Guangzhou,China
-
LED Configuration:
-
SMD1921
-
Pixel Density:
-
32768dot/m2
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
Hosen
-
Panel Size:
-
500x1000, 500x1000
-
Place of Origin:
-
Guangdong, China
-
name:
-
P3.91 led display screen
-
Power:
-
AC-100-240V
-
Brand:
-
Hosen
-
Made in:
-
Guangzhou,China
-
LED Configuration:
-
SMD1921
-
Pixel Density:
-
32768dot/m2
500*500mm Outdoor waterproof HD screen led video wall panel display P3.91 ,P4.81 Curve Stage Backdrop Led Video Wall screen
The see-through LED transparent screen is an innovation that reduces the impact on architectural aesthetics, improves perspective and provides a new and unique display.
The screen consists of lightweight modules of different sizes (different pixel pitches are available according to project needs).
It is highly adaptable, moisture-proof, dust-proof, easy to maintain, and has a solid structure that is not easily damaged.
High brightness High refresh
Brightness up to 6500CD.
Can be used during the daytime using high efficiency LED lights under the same brightness conditions with lower energy consumption.
IP65 Waterproof
Lamp bead filling and power box sealing treatment
Ensure good waterproof performance, can be used normally in rainy days.
| Pixel Pitch | H3.91-V8.9mm | H3.9-V7.8mm | H10.4-V10.4mm |
| LED Configuration | SMD1921 | SMD1921 | SMD1921 |
| Pixel Density | 28224dot/m2 | 32768dot/m2 | 9216dot/m2 |
| Transparency | 42% | 42% | 58% |
| Scan Mode | 7S | 8S | 2S |
| Module Size | 500X125mm | 500X125mm | 500X125mm |
| Bar Resolution | 126X14dot | 128X16dot | 48X12dot |
| Cabinet Size | 1000X500mm | 1000X500mm | 1000X500mm |
| Cabinet Resolution | 252X56dot | 256X64dot | 96X48dot |
| Viewing Distance | >5m | >5m | >10m |
| Max.Power Consumption | 800W/m² | ||
| Ave. Power Consumption | 260W/m² | ||
| Gray Scale | 14-16bit | ||
| Cabinet Weight | 7kg/Panel | ||
| IP Rating ( front/back) | IP65 | ||
| Brightness | 5000CD/m2 | ||
| Viewing Angle (H/V) | 120°/120° | ||
| Refresh Rate | ≥3840Hz | ||
| Environment | OUTDOOR | ||
| Control Mode | Synchronous display with control PC by DVI | ||
| Support Input | Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI | ||
| Operation Power | AC110~ 240V, 50/60Hz | ||
| Operating Temperature | - 30°C~60°C | ||
| Operating Humidity | 10%~90% | ||
| Operating Life | ≥100,000hours | ||
Video processor 820H Connection Diagram
