Quick Details
-
Panel Dimensions:
-
26*85.6*0.06 inches
-
Panel Efficiency:
-
100w
-
Type:
-
CIGS
-
Core type:
-
CIGS
-
Max Power (Pmax):
-
200±5%W
-
Solar Cells Efficiency:
-
16%
-
Max. Power Voltage Vmp (V):
-
25±5%V
-
Max. Power Current Imp (A):
-
8.02±5%A
-
Open Circuit Voltage Voc (V):
-
31.5±5%V
-
Short Circuit Current (Isc):
-
8.64±5%A
-
Max. System Voltage:
-
1000V DC
-
Performance Warranty:
-
25 years
-
Series Fuse Rating:
-
10A
Quick Details
-
Brand Name:
-
Sangsolar
-
Model Number:
-
HW-MQSG-V1
-
Place of Origin:
-
Beijing, China
-
Panel Dimensions:
-
26*85.6*0.06 inches
-
Panel Efficiency:
-
100w
-
Type:
-
CIGS
-
Core type:
-
CIGS
-
Max Power (Pmax):
-
200±5%W
-
Solar Cells Efficiency:
-
16%
-
Max. Power Voltage Vmp (V):
-
25±5%V
-
Max. Power Current Imp (A):
-
8.02±5%A
-
Open Circuit Voltage Voc (V):
-
31.5±5%V
-
Short Circuit Current (Isc):
-
8.64±5%A
-
Max. System Voltage:
-
1000V DC
-
Performance Warranty:
-
25 years
-
Series Fuse Rating:
-
10A
Products Description
Products Specification
|
SANG
|
ISE138
|
|
Core Material
|
CIGS
|
|
Bendability
|
Excellent Bendability
|
|
Weight
|
Lightweight
|
|
Fragility
|
Hardly Damaged
|
|
Max Power (Pmax)
|
200±5％W
|
|
Solar Cells Efficiency
|
16%
|
|
Max. Power Voltage Vmp (V)
|
25±5％V
|
|
Max. Power Current Imp (A)
|
8.02±5％A
|
|
Open Circuit Voltage Voc (V)
|
31.5±5％V
|
|
Short Circuit Current (Isc)
|
8.64±5％A
|
|
Max. System Voltage
|
1000V DC
|
|
Warranty Description
|
10+2 Years(Exclusive benefit for purchases made on the BougeRV official website.)
|
|
Performance Warranty
|
25 years
|
|
Operating Temperature Limits
|
-40℉ ~ +185℉
|
|
Series Fuse Rating
|
10A
|
|
Temperature Coefficient Pmax
|
-0.38%/℃
|
|
Temperature Coefficient Voc
|
-0.28%/℃
|
|
Temperature Coefficient Isc
|
-0.008%/℃
|
|
Dimensions
|
26*85.6*0.06 inches
|
|
Weight
|
7.05 lbs
|
