Quick Details
-
Warranty:
-
25 YEARS
-
Brand Name:
-
Trina
-
Model Number:
-
Solar Panels
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2384 x 1303 x 30mm
-
Weight:
-
33.6kg
-
Front Side Glass:
-
High transparency solar glass 2.0mm
-
Back Side Glass:
-
High transparency solar glass 2.0mm
-
Frame:
-
Silver / Black, anodized aluminium alloy
-
Junction Box:
-
IP68 Rated, 3 Diodes
-
Cable::
-
4.0mm2, Portrait: 300mm / Landscape: 1200mm
-
Wind/Snow Load:
-
2400Pa/5400Pa
-
Connector:
-
MC Compatible
-
Application:
-
Residencial,Commercial & Industry
-
Bifaciality:
-
70±5%
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, HJT, ALL Black
-
Panel Efficiency:
-
22%
-
Warranty:
-
25 YEARS
-
Brand Name:
-
Trina
-
Model Number:
-
Solar Panels
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2384 x 1303 x 30mm
-
Weight:
-
33.6kg
-
Front Side Glass:
-
High transparency solar glass 2.0mm
-
Back Side Glass:
-
High transparency solar glass 2.0mm
-
Frame:
-
Silver / Black, anodized aluminium alloy
-
Junction Box:
-
IP68 Rated, 3 Diodes
-
Cable::
-
4.0mm2, Portrait: 300mm / Landscape: 1200mm
-
Wind/Snow Load:
-
2400Pa/5400Pa
-
Connector:
-
MC Compatible
-
Application:
-
Residencial,Commercial & Industry
-
Bifaciality:
-
70±5%
Product Description
Specification
|
ELECTRICAL PARAMETERS
|
|
|
|
|
|
|
||||||
|
TYPE
|
JAM60S20 -365/MR
|
|
JAM60S20 -370/MR
|
|
JAM60S20 -375/MR
|
|
||||||
|
Testing Condition
|
STC
|
NOCT
|
STC
|
NOCT
|
STC
|
NOCT
|
||||||
|
Rated Maximum Power(Pmax) [W]
|
365
|
276
|
370
|
280
|
375
|
284
|
||||||
|
Open Circuit Voltage(Voc) [V]
|
41.13
|
38.41
|
41.30
|
38.65
|
41.45
|
38.89
|
||||||
|
Maximum Power Voltage(Vmp) [V]
|
33.96
|
32.05
|
34.23
|
32.30
|
34.50
|
32.55
|
||||||
|
Short Circuit Current(lsc) [A]
|
11.30
|
9.15
|
11.35
|
9.20
|
11.41
|
9.25
|
||||||
|
Maximum Power Current(lmp) [A]
|
10.75
|
8.61
|
10.81
|
8.66
|
10.87
|
8.71
|
||||||
|
Module Efficiency [%]
|
19.5
|
|
19.8
|
|
20.1
|
|
||||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Isc(α-jsc)
|
+0.044%/°C
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Voc(β_Voc)
|
-0.272%/°C
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Pmax(γ_Pmp)
|
-0.350%/°C
|
|
|
|
|
|
||||||
|
STC
|
Irradiance 1000W/m², cell temperature 25°C, AM1.5G
|
|
|
|
|
|
||||||
|
NOCT
|
Irradiance 800W/m², ambient temperature 20°C, wind speed 1m/s, AM1.5G
|
|
|
|
|
|
||||||
|
Remark: Electrical data in this catalog do not refer to a single module and they are not part of the offer.They only serve for
comparison among different module types. |
|
|
|
|
|
|
||||||
