Quick Details
-
Voltage:
-
220V
-
Power:
-
3500W
-
Weight:
-
15 kg
-
Power Source:
-
Electric
-
Product name:
-
Wall slotting machine
-
Slotting width:
-
42mm
-
Dust removal method:
-
Water wet / wind suction
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HS
-
Cutting Depth:
-
20cm
-
Voltage:
-
220V
-
Power:
-
3500W
-
Weight:
-
15 kg
-
Power Source:
-
Electric
-
Product name:
-
Wall slotting machine
-
Slotting width:
-
42mm
-
Dust removal method:
-
Water wet / wind suction
Product Paramenters
|
Product name
|
Gasoline Road Cutter
|
Diesel Road Cutter
|
Large Road Diesel Cutting Machine
|
Small gasoline road cutter
|
Medium and large electric cutting machine
|
|
Power
|
13Hp
|
6.3/7.5/8.2kw
|
15, 17, 22P
|
6.5P
|
7.5KW
|
|
Saw line speed
|
36-49m/s
|
36-49m/s
|
36-45m/h
|
-
|
36-49m/s
|
|
Maximum depth of cut
|
180mm
|
180mm
|
0-34CM
|
0-8CM
|
180mm
|
|
Water tank capacity
|
37L
|
37L
|
40L
|
20L
|
37L
|
|
Saw blade diameter
|
300-500mm
|
300-500mm
|
600-800mm
|
300-350mm
|
300-500mm
|
|
Product weight
|
110kg
|
140kg
|
360KG
|
70KG
|
120kg
|
|
Dimensions
|
135*55*90cm
|
135*55*90cm
|
-
|
-
|
140*60*90cm
|
|
Product name
|
Concrete circular cutting machine
|
|
Power
|
Gasoline Diesel Powered
|
|
Engine
|
GX390/Loncin 420
|
|
Power
|
13HP
|
|
Cutting depth
|
100-130mm
|
|
Cutting diameter circumference
|
1200mm-1700mm
|
|
Blade size
|
450mm diamond saw blade
|
|
Insert bore diameter
|
27mm
|
|
Tank volume
|
30L
|
|
Full vehicle width
|
1200mm
|
|
Work efficiency
|
20-30min/pc
|
|
Rotating speed
|
3600rpm
|
|
Main dimensions
|
1550*900*850mm
|
|
Weight
|
200kg
|
|
Product name
|
Pavement engraving machine
|
|
Power
|
7.5KW
|
|
Tank volume
|
50L
|
|
Saw blade diameter
|
300/400/500mm
|
|
Maximum depth of cut
|
180MM
|
|
Number of engraved sheets
|
18 pieces
|
|
Diameter of engraved sheet
|
150MM
|
|
Engraving depth
|
10MM-20MM
|
|
Package dimensions
|
1300*900*1100MM
|
|
way of walking
|
Automatic walking
|
|
Total Weight
|
230KG
|
|
Product name
|
Gasoline cutting and engraving machine
|
Diesel cutting and engraving machine
|
Electric cutting and engraving machine
|
|
Power
|
13P
|
Chang Gong
|
7.5KW
|
|
Tank volume
|
40L
|
45L
|
50L
|
|
Saw blade diameter
|
400-500MM
|
300-500MM
|
400-500MM
|
|
Maximum depth of cut
|
180MM
|
180MM
|
180MM
|
|
Number of engraved sheets
|
14 pieces
|
14 pieces
|
18 pieces
|
|
Diameter of engraved sheet
|
150MM
|
150MM
|
150MM
|
|
Engraving depth
|
2-5MM
|
2MM-5MM
|
10MM-20MM
|
|
Package dimensions
|
1150*720*950MM
|
1150*720*950MM
|
1300*900*1100MM
|
|
way of walking
|
Walk by hand
|
-
|
Automatic walking
|
|
Total Weight
|
110KG
|
146KG
|
230KG
|
|
Zong method
|
-
|
Hand pull/electric start
|
-
|
|
Product name
|
Concrete pile cutter
|
|
Electromechanical voltage
|
380V
|
|
Motor power
|
9KW/11KW
|
|
Spindle speed
|
1440r/min
|
|
Total Weight
|
130KG-150KG
|
|
Can be installed
|
300-800 type data sheet
|
|
Cutting depth
|
0-25cm
|
|
Swivel angle
|
360°
|
|
Water tank capacity
|
12L
|
|
Spindle speed
|
1800r/min
|
|
Whether to lift
|
Customizable
|
|
Product name
|
Wall slotting machine
|
Wall cutter machine
|
|
Rated voltage
|
220V
|
220V
|
|
Maximum power
|
8980W
|
2200W
|
|
Net weight
|
6.3kg
|
5.0kg
|
|
Slotting width
|
42mm
|
-
|
|
Rotating speed
|
-
|
8500r/min
|
|
Slotting depth
|
40mm
|
55mm
|
|
Saw blade specification
|
133*20*4.5mm
|
-
|
|
Disc diameter
|
-
|
195mm
|
|
Dust removal method
|
Water wet / wind suction
|
-
|
|
Wall cutting machine
|
|
|
|
|||
|
Model
|
800
|
1000
|
1200
|
|||
|
Weight
|
80kg
|
105kg
|
125kg
|
|||
|
Rated voltage
|
220V
|
220V
|
220V
|
|||
|
Cutting depth
|
30cm
|
40cm
|
50cm
|
|||
|
Rated power
|
6.28kW
|
6.68kW
|
7.68kW
|
|||
|
Type
|
Manual / semi-automatic / fully automatic
|
|
|
|||
|
Product name
|
Ground slotting machine
|
|
Load power
|
8800W
|
|
Rated power
|
3800W
|
|
Speed
|
6800r/min
|
|
Cutting depth
|
160mm
|
|
Standard configuration
|
410 saw blade
|
|
Blade steering
|
Forward rotation
|
|
Bare weight
|
13.5kg
|
Product Advantages
Application
The above machines are widely used in the construction of high-speed railways, highways, bridges, rivers, and ports, which solve the headache problem in construction and have high speed and high efficiency.
