Quick Details
-
Design Printing:
-
No printing
-
Material:
-
Acrylic foam
-
Feature:
-
Waterproof
-
Use:
-
MASKING
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
3M
-
Model Number:
-
4905
-
Color:
-
Transparent
Quick Details
-
Adhesive:
-
Acrylic
-
Adhesive Side:
-
Single Sided
-
Adhesive Type:
-
Pressure Sensitive
-
Design Printing:
-
No printing
-
Material:
-
Acrylic foam
-
Feature:
-
Waterproof
-
Use:
-
MASKING
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
3M
-
Model Number:
-
4905
-
Color:
-
Transparent
3M™ VHB™ Tape 4905 is a 0.020 inch (0.5 mm) thick clear double coated acrylic foam tape with PE film liner. The general purpose acrylic adhesive on both sides bonds to a broad range of high surface energy substrates including metals, glass and easier to bond paints and plastics. The clear tape is good for bonding transparent or translucent materials or for applications where colorless is a benefit.
Product Features
• Fast and easy-to-use permanent bonding method provides high strength and long-term durability
• Virtually invisible fastening keeps surfaces smooth
• Can replace mechanical fasteners (rivets, welds, screws) or liquid adhesives for transparent applications
• Clear, 0.020 in (0.5 mm), general purpose adhesive and clear acrylic core
• Eliminate drilling, grinding, refinishing, screwing, welding and associated clean-up
• Creates a permanent seal against water, moisture and more
• Pressure sensitive adhesive bonds on contact to provide immediate handling strength
• Allows the use of thinner, lighter weight and dissimilar materials
Typical Physical Properties
| Property | Values | Method | Notes | Test Name | |
|---|---|---|---|---|---|
| Thickness Tolerance | ±15 % | ||||
| Density | 960 kg/m³ | 60 lb/ft³ | ASTM D3574 | Foam with adhesive | |
| Liner Thickness | 0.005 in | 0.13 mm | |||
| Color | Clear | ||||
| Adhesive Type | General Purpose Acrylic | ||||
| Foam Type | Solid Acrylic | ||||
| Liner | PE Film | ||||
| Liner Color | Red (printed) | Primary |
Recommended Applications
- Joining transparent material
- Mount backlit translucent signs
- Edge-bond resin filled glass
- Metal, glass and high surface energy (HSE) substrates
- Decorative material and trim
- Nameplates and logos
- Panel to frame
- Stiffener to panel
