- Product Details
- {{item.text}}
Quick Details
-
Warranty(Year):
-
2-Year
-
Product Weight（kg）:
-
0.6
-
Lamp Luminous Flux(lm):
-
600
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Clen
-
Emitting Color:
-
changeable
-
LED Type:
-
5050 RGB EPISTAR
-
PCB Color:
-
Black PCB
-
Voltage:
-
DC24V
-
LED QTY:
-
64LEDS
-
IC Type:
-
Sk6812
-
Material:
-
Aluminunm PCB
-
Product Name:
-
Video LED bar
-
Lamp Power:
-
15W
-
Switch Mode:
-
Manual Button
Quick Details
-
Color Temperature(CCT):
-
full-color
-
Type:
-
Projection Lights
-
Application:
-
Theme Park
-
Warranty(Year):
-
2-Year
-
Product Weight（kg）:
-
0.6
-
Lamp Luminous Flux(lm):
-
600
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 60
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Clen
-
Emitting Color:
-
changeable
-
LED Type:
-
5050 RGB EPISTAR
-
PCB Color:
-
Black PCB
-
Voltage:
-
DC24V
-
LED QTY:
-
64LEDS
-
IC Type:
-
Sk6812
-
Material:
-
Aluminunm PCB
-
Product Name:
-
Video LED bar
-
Lamp Power:
-
15W
-
Switch Mode:
-
Manual Button
1M 24V RGB Pixel Led Bar For Stage Nightclub DJ Events
Descriptions
Brilliant and bright colours come to you with the LED bar. Clubs, bars, shops and stages are the ideal locations for this slender instrument. It is also the perfect device for interesting light creations in your own rooms. LEDs have a high performance, are very bright and shed a strong and intense light. This is naturally also true for the LED bar. Common lamps can be used about 2.000 hours in lighting engineering. This is only a fraction of LED’s longevity, which can bring you approx. 50.000 hours of light. The LEDs in the LED bar consume only little energy. Additionally, they dissipate only little heat. This is not only good for your energy balance, it is also good for the environment.
| Product name | LED Pixel Bar |
| Voltage | DC24V |
| IC Type | SK6812 |
| LED Type | SMD5050RGB |
| LED quanitity | 64pcs/meter |
| Pixel | 64 pcs/meter |
| Max wattage | 15W |
| Greyscale | 256 |
| Waterproof Grade | IP65 |
| Model Number |
CL-
VB5050RGB64-5
|
| Color |
Full color RGB
|
Product installation diagram
Installation
1. Input: at the needle side.Output: at the hole side.
2. DI of strip connect the DO of controller
3. If the strip is more than 10M, need a signal amplifier to increase the transmit-ability
4. Special design between 2 strips which realize seamless integrate.
5. T he lamp holder can be fixed by the internal sliding bar of the botto m sliding groove.
Note
1. Please choose our DVI control box for installation of the project.
2. Controller with 8 out port,each out port control 512 pixels
3 . Power supply and controller inside the control box, the strip connect the output of controller,no need extra driver.
Advantages
1) DVI Control Mode
2)SK6812 single signal transmission
3) Single led per single pixel point Serial tansimission
4) Seamless Connection
5) Break point Continuous
6) Without voltage drop even if several joint
1. Holiday decoration lighting, Christmas party, holiday time, anywhere you want to produce a particularly eye-catching display.
2. Market Engineering lighting, architectural decoration, decoration of trees along streets, parks, urban night lighting.
3. Attractions landscaping, gardening, community night crystal decoration, hotels, shopping malls, night entertainment.
